– 62 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CDP-X3000/X3000ES
MISCELLANEOUS
**************
63 1-777-923-11 WIRE (FLAT TYPE) (7 CORE)
64 1-777-924-11 WIRE (FLAT TYPE) (23 CORE)
! 107 1-558-568-21 CORD, POWER
153 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
159 1-777-741-11 WIRE (FLAT TYPE) (6 CORE)
! 164 8-848-379-31 OPTICAL PICK-UP KSS-213B/S-N
M101 X-4947-303-1 MOTOR ASSY (SLED)
M102 X-4948-273-1 MOTOR ASSY (SPINDLE)
! T1 1-431-227-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-132-19 SCREW +BTP 2.6X5 TYPE2 N-S
#2 7-685-870-01 SCREW +BVTT 3X5 (S)
#3 7-685-871-09 SCREW +BVTT 3X6 (S)
#4 7-621-775-08 SCREW +P 2.6X3
#5 7-621-773-95 SCREW +B 2.6X6
#6 7-621-770-67 SCREW +P 2.6X6
#7 7-685-874-09 SCREW +BVTT 3X12 (S)
#8 7-621-775-10 SCREW +P 2.6X4
#9 7-685-872-09 SCREW +BVTT 3X8 (S)
#10 7-627-852-07 SCREW, PRECISION +P 1.7X2.5
#11 7-685-880-09 SCREW +BVTT 4X6 (S)
#12 7-685-871-01 SCREW +BVTT 3X6 (S)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-473-943-11 REMOTE COMMANDER (RM-DX3000)
1-558-271-11 CORD, CONNECTION (AUDIO PIN CORD)
3-858-684-11 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
SPANISH, PORTUGUESE, CHINESE) (X3000ES)
3-858-684-21 MANUAL, INSTRUCTION (GERMAN, ITALIAN,
DUTCH, SWEDISH) (X3000ES)
4-981-643-01 COVER, BATTERY (for RM-DX3000)
X-4947-761-1 STABILIZER ASSY
9-960-918-11
Sony Corporation
Home A&V Products Company
97D0559-1
Printed in Japan © 1997. 4
Published by General Engineering Dept.
(Shibaura)
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
