— 36 —
CDP-XE700
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R932 1-249-436-11 CARBON 39K 5% 1/4W
R933 1-247-807-31 CARBON 100 5% 1/4W
R934 1-249-421-11 CARBON 2.2K 5% 1/4W
R935 1-249-422-11 CARBON 2.7K 5% 1/4W
R937 1-249-417-11 CARBON 1K 5% 1/4W
R938 1-247-807-31 CARBON 100 5% 1/4W
R939 1-249-425-11 CARBON 4.7K 5% 1/4W
R940 1-249-423-11 CARBON 3.3K 5% 1/4W
R941 1-249-428-11 CARBON 8.2K 5% 1/4W
R942 1-249-425-11 CARBON 4.7K 5% 1/4W
R943 1-249-425-11 CARBON 4.7K 5% 1/4W
R950 1-247-807-31 CARBON 100 5% 1/4W
< VIBRATOR >
X301 1-579-834-11 VIBRATOR, CRYSTAL (33.8688MHz)
**************************************************************
* 1-658-819-11 POWER BOARD
*************
* 4-962-200-01 PLATE (TR), GROUND
< CAPACITOR >
C901 1-164-159-21 CERAMIC 0.1uF 50V
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-164-159-21 CERAMIC 0.1uF 50V
C904 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
**************************************************************
* 1-658-709-11 SLED BOARD
***********
< CONNECTOR >
CN104 1-774-380-11 CONNECTOR, FFC/FPC 16P
CN105 1-568-838-11 SOCKET, CONNECTOR 21P
* CN106 1-750-737-11 CONNECTOR, FFC/FPC 5P
**************************************************************
* 1-658-708-11 SPINDLE BOARD
**************
< CONNECTOR >
* CN107 1-568-848-11 SOCKET, CONNECTOR 5P
< SWITCH >
S151 1-571-958-11 SWITCH, PUSH (1 KEY)(LIMIT SW)
**************************************************************
MISCELLANEOUS
***************
55 1-776-235-11 WIRE (FLAT TYPE) (23 CORE)
101 1-452-820-11 MAGNET (ASSY)
105 1-776-998-11 WIRE (FLAT TYPE) (21 CORE)
157 1-775-990-11 WIRE (FLAT TYPE) (5 CORE)
! 160 8-848-376-01 OPTICAL PICK-UP KSS-213B/S-N
161 1-775-991-11 WIRE (FLAT TYPE) (16 CORE)
M101 X-4947-304-1 MOTOR ASSY (SPINDLE)
M102 X-4947-303-1 MOTOR ASSY (SLED)
M151 A-4660-968-A MOTOR ASSY (LOADING)
! CNP901 1-575-651-21 CORD, POWER (AEP,G)
! CNP901 1-696-907-11 CORD, POWER (UK)
! T901 1-429-367-11 TRANSFORMER, POWER
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-473-125-11 REMOTE COMMANDER (RM-D820)
1-558-271-11 CORD, CONNECTION (AUDIO 108cm)(AEP,G)
1-590-925-31 CORD, CONNECTION (AUDIO 100cm)(UK)
3-810-116-11 MANUAL, INSTRUCTION
(ENGLISH,FRENCH,SPANISH,SWEDISH)(AEP,UK)
3-810-116-21 MANUAL, INSTRUCTION
(GERMAN,DUTCH,ITALIAN,PORTUGUESE)(AEP)
3-810-116-31 MANUAL, INSTRUCTION (GERMAN)(G)
4-962-615-01 COVER, BATTERY (for RM-D820)
* 4-979-127-01 INDIVIDUAL CARTON (AEP,G)
* 4-979-127-11 INDIVIDUAL CARTON (UK)
* 4-982-101-01 CUSHION
**************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3X6 (S)
#3 7-682-548-04 SCREW +BVTT 3X8 (S)
#4 7-627-852-07 SCREW, PRECISION +P 1.7X2.5
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
9-960-633-11
Sony Corporation
Consumer A&V Products Company
Home A&V Products Div.
English
96D097558-1
Printed in Germany
© 1996. 4
Published by Home A&V Products Div.
Quality Engineering Dept.
MAIN POWER
SLED
SPINDLE
