Sony CDX-4250 - Electrical Parts List (Continued); Capacitors and Resistors Lists

– 46 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R587 1-216-186-00 RES,CHIP 330 5% 1/8W
R588 1-216-186-00 RES,CHIP 330 5% 1/8W
R591 1-216-183-00 RES,CHIP 240 5% 1/8W
R592 1-216-183-00 RES,CHIP 240 5% 1/8W
R593 1-216-183-00 RES,CHIP 240 5% 1/8W
R594 1-216-183-00 RES,CHIP 240 5% 1/8W
R595 1-216-183-00 RES,CHIP 240 5% 1/8W
R596 1-216-183-00 RES,CHIP 240 5% 1/8W
R597 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R598 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
< ROTARY ENCODER >
RE551 1-475-014-11 ENCODER, ROTARY
< SWITCH >
S551 1-572-704-31 SWITCH, KEY BOARD (6)
S552 1-572-704-31 SWITCH, KEY BOARD (DSPL)
S553 1-572-704-31 SWITCH, KEY BOARD (SENS)
S554 1-572-704-31 SWITCH, KEY BOARD (SOUND)
S555 1-762-719-21 SWITCH, TACT (MODE)
S556 1-771-290-11 SWITCH, SLIDE
(SEEK/AMS = 0 -/+ ) +)
S557 1-572-704-31 SWITCH, KEY BOARD (1)
S558 1-572-704-31 SWITCH, KEY BOARD (2)
S561 1-572-704-31 SWITCH, KEY BOARD (OFF)
S562 1-572-704-31 SWITCH, KEY BOARD (SOURCE)
S563 1-572-704-31 SWITCH, KEY BOARD (3)
S564 1-572-704-31 SWITCH, KEY BOARD (4)
S565 1-572-704-31 SWITCH, KEY BOARD (5)
S566 1-572-704-31 SWITCH, KEY BOARD (6)
S567 1-762-937-11 SWITCH, ROTARY (D-BASS)
**************************************************************
* 1-659-835-12 LIMIT BOARD
***********
< SWITCH >
SW3 1-572-688-11 SWITCH, PUSH (1 KEY)
**************************************************************
* 1-659-837-11 LOAD BOARD
**********
< SWITCH >
SW4 1-572-288-21 SWITCH, PUSH
**************************************************************
* A-3294-551-A MAIN BOARD, COMPLETE (CDX-4250)
*********************
* A-3294-631-A MAIN BOARD, COMPLETE (CDX-4500)
*********************
* 3-019-565-01 BRACKET (IC)
* 3-030-849-01 HEAT SINK (T)
* 3-030-850-01 HEAT SINK (REG)
7-685-792-09 SCREW +PTT 2.6X6 (S)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C101 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C102 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C104 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
(CDX-4250)
C104 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
(CDX-4500)
C105 1-124-233-11 ELECT 10uF 20% 16V
C106 1-124-233-11 ELECT 10uF 20% 16V
C107 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C110 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C111 1-164-346-11 CERAMIC CHIP 1uF 16V
C112 1-164-346-11 CERAMIC CHIP 1uF 16V
C113 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C114 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C115 1-124-233-11 ELECT 10uF 20% 16V
C116 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C117 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C118 1-124-233-11 ELECT 10uF 20% 16V
C201 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C202 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C203 1-164-346-11 CERAMIC CHIP 1uF 16V
C205 1-124-233-11 ELECT 10uF 20% 16V
C206 1-124-233-11 ELECT 10uF 20% 16V
C207 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C208 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C210 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C211 1-164-346-11 CERAMIC CHIP 1uF 16V
C212 1-164-346-11 CERAMIC CHIP 1uF 16V
C213 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C214 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C215 1-124-233-11 ELECT 10uF 20% 16V
C216 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C217 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C218 1-124-233-11 ELECT 10uF 20% 16V
C401 1-124-233-11 ELECT 10uF 20% 16V
C405 1-126-514-11 ELECT 22uF 20% 16V
C407 1-124-259-11 ELECT 4.7uF 20% 16V
C408 1-164-346-11 CERAMIC CHIP 1uF 16V
C409 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C410 1-126-786-11 ELECT 47uF 20% 16V
(CDX-4500)
C411 1-124-465-00 ELECT 0.47uF 20% 50V
C412 1-164-346-11 CERAMIC CHIP 1uF 16V
C413 1-124-589-11 ELECT 47uF 20% 16V
C414 1-164-346-11 CERAMIC CHIP 1uF 16V
(CDX-4500)
C601 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C602 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C603 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C604 1-126-514-11 ELECT 22uF 20% 16V
C605 1-163-031-11 CERAMIC CHIP 0.01uF 50V
DISPLAY MAINLIMIT
LOAD
