Sony CDX-4250 - Electrical Parts List (Continued); Tuner, Connector, IC, and Vibrator Parts

– 47 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C609 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C610 1-124-233-11 ELECT 10uF 20% 16V
C611 1-124-464-11 ELECT 0.22uF 20% 50V
C612 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C613 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C614 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(CDX-4500)
C614 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(CDX-4250)
C615 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
(CDX-4500)
C615 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
(CDX-4250)
C617 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C619 1-163-018-00 CERAMIC CHIP 5600PF 10% 50V
(CDX-4250)
C619 1-163-020-00 CERAMIC CHIP 0.0082uF 10% 50V
(CDX-4500)
C625 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C701 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C702 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C703 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C704 1-124-233-11 ELECT 10uF 20% 16V
C705 1-124-589-11 ELECT 47uF 20% 16V
C708 1-124-233-11 ELECT 10uF 20% 16V
C709 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C712 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C713 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C714 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(CDX-4250)
C801 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(CDX-4250)
C802 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C804 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C805 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C807 1-163-233-11 CERAMIC CHIP 18PF 5% 50V
C808 1-163-234-11 CERAMIC CHIP 20PF 5% 50V
C814 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C830 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C831 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C901 1-124-257-00 ELECT 2.2uF 20% 50V
C902 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C903 1-124-257-00 ELECT 2.2uF 20% 50V
C904 1-110-654-11 ELECT(BLOCK) 0.047F 0% 0
C907 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C908 1-124-465-00 ELECT 0.47uF 20% 50V
C909 1-126-768-11 ELECT 2200uF 20% 16V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C911 1-124-259-11 ELECT 4.7uF 20% 16V
C913 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C915 1-126-162-11 ELECT 3.3uF 20% 50V
C916 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CNJ601 1-785-006-11 JACK (ANT)
CNP701 1-764-617-12 PIN, CONNECTOR (PC BOARD) 30P
CNP801 1-764-422-11 PLUG, CONNECTOR 12P
CNP901 1-774-701-11 PIN, CONNECTOR 16P
< COMPOSITION CIRCUIT BLOCK >
CP601 1-519-504-11 GAP, DISCHARGE
< DIODE >
D401 8-719-109-71 DIODE RD3.9ES-B1
D402 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D701 8-719-991-33 DIODE 1SS133T-77
D801 8-719-109-93 DIODE RD6.2ESB2
D802 8-719-109-93 DIODE RD6.2ESB2
D803 8-719-109-93 DIODE RD6.2ESB2
D804 8-719-109-93 DIODE RD6.2ESB2
D805 8-719-109-93 DIODE RD6.2ESB2
D807 8-719-109-93 DIODE RD6.2ESB2
D808 8-719-109-93 DIODE RD6.2ESB2
D809 8-719-109-93 DIODE RD6.2ESB2
D811 8-719-991-33 DIODE 1SS133T-77
D812 8-719-109-93 DIODE RD6.2ESB2
D901 8-719-929-15 DIODE MTZJ-T-77-9.1B
D902 8-719-929-15 DIODE MTZJ-T-77-9.1B
D903 8-719-109-89 DIODE RD5.6ESB2
D904 8-719-109-89 DIODE RD5.6ESB2
D905 8-719-109-93 DIODE RD6.2ESB2
D906 8-719-923-91 DIODE MTZJ-T-77-16A
D907 8-719-049-38 DIODE 1N5404TU
D908 8-719-200-82 DIODE 11ES2
D910 8-719-109-93 DIODE RD6.2ESB2
D911 8-719-991-33 DIODE 1SS133T-77
D921 8-719-109-97 DIODE RD6.8ES-B2
< IC >
IC401 8-759-487-82 IC LC75374E
IC402 8-759-490-74 IC TDA7384
IC701 8-759-464-81 IC PCM1717E-ST2
IC801 8-759-585-18 IC uPD17P709GC-537-3B9
< JUMPER RESISTOR >
JR3 1-216-295-00 SHORT 0
JR4 1-216-296-00 SHORT 0
JR5 1-216-296-00 SHORT 0
JR7 1-216-296-00 SHORT 0
JR11 1-216-296-00 SHORT 0
JR16 1-216-295-00 SHORT 0
JR17 1-216-296-00 SHORT 0
JR18 1-216-295-00 SHORT 0
JR19 1-216-296-00 SHORT 0
JR22 1-216-295-00 SHORT 0
JR24 1-216-295-00 SHORT 0
JR31 1-216-296-00 SHORT 0
JR33 1-216-295-00 SHORT 0
JR35 1-216-296-00 SHORT 0
JR36 1-216-296-00 SHORT 0
JR37 1-216-296-00 SHORT 0
JR39 1-216-295-00 SHORT 0
JR45 1-216-296-00 SHORT 0
JR46 1-216-296-00 SHORT 0
JR48 1-216-295-00 SHORT 0
MAIN
