Sony CDX-540RF - Electrical Parts List; Component Parts Lists

43
SECTION 9
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
* A-3326-027-A FM BOARD, COMPLETE
*******************
< CAPACITOR >
C301 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C303 1-127-820-11 CERAMIC CHIP 4.7uF 16V
C304 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C305 1-128-499-11 ELECT 220uF 20% 16V
C319 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C320 1-115-866-11 ELECT 4.7uF 20% 35V
C322 1-125-972-61 ELECT 100uF 20% 16V
C323 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C324 1-124-584-00 ELECT 100uF 20% 10V
C325 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C326 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C328 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C329 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C331 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C701 1-126-514-11 ELECT 22uF 20% 10V
C702 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C704 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C705 1-115-866-11 ELECT 4.7uF 20% 35V
C706 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C707 1-162-997-11 CERAMIC CHIP 10PF 0.5PF 50V
C708 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C709 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C710 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C711 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C712 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C713 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C714 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C715 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C716 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C720 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C741 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C742 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C743 1-115-872-11 ELECT 2.2uF 20% 50V
C761 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C762 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C763 1-115-872-11 ELECT 2.2uF 20% 50V
C781 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C782 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C783 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C784 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C785 1-126-514-11 ELECT 22uF 20% 10V
C786 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C787 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C788 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR/JACK >
CN302 1-794-066-11 CONNECTOR, MINIATURE DIN 8P (DISPLAY)
CN303 1-793-286-11 PIN, CONNECTOR (PC BOARD) 3P (POWER)
CN701 1-784-829-21 CONNECTOR, FPC 21P
CN703 1-566-822-41 JACK (OUTPUT)
< DIODE >
D301 8-719-029-25 DIODE DSA3A4-F2
D302 8-719-022-90 DIODE MA8160-M
D310 8-719-423-23 DIODE MA8110-M
D311 8-719-977-12 DIODE DTZ6.8B
D312 8-719-801-78 DIODE 1SS184
D313 8-719-977-12 DIODE DTZ6.8B
D314 8-719-977-12 DIODE DTZ6.8B
D701 8-719-058-78 DIODE HVU202A3TRF
D702 8-719-988-61 DIODE 1SS355TE-17
D703 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC304 8-759-711-59 IC NJM78L05UA-TE1
IC701 8-759-393-50 IC BA1405F-E2
IC781 8-759-595-05 IC BU2611AFS-E2
< COIL >
L301 1-419-545-11 COIL, CHOKE 1mH
L701 1-419-467-11 COIL, IFT
L702 1-411-845-11 COIL, AIR-CORE
L703 1-410-997-42 INDUCTOR CHIP 2.2uH
< TRANSISTOR >
Q301 8-729-900-53 TRANSISTOR DTC114EK
Q308 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q309 1-801-806-11 TRANSISTOR DTC144EKA
Q310 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q311 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q701 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q702 8-729-804-72 TRANSISTOR 2SC2814-F4
Q703 8-729-804-72 TRANSISTOR 2SC2814-F4
Q781 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
FM
