45
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C318 1-126-382-11 ELECT 100uF 20% 16V
C319 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C320 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C401 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C402 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C404 1-126-157-11 ELECT 10uF 20% 16V
C405 1-126-157-11 ELECT 10uF 20% 16V
C406 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C407 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C416 1-126-382-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN231 1-784-829-21 CONNECTOR, FPC 21P
< DIODE >
D201 8-719-978-33 DIODE DTZ-TT11-6.8B
D202 8-719-978-33 DIODE DTZ-TT11-6.8B
D231 8-719-988-61 DIODE 1SS355TE-17
D306 8-719-069-56 DIODE UDZS-TE17-6.2B
D307 8-719-988-61 DIODE 1SS355TE-17
D308 8-719-914-94 DIODE DAP202K
D309 8-719-988-61 DIODE 1SS355TE-17
D310 8-719-422-67 DIODE MA8062-H
D311 8-719-978-33 DIODE DTZ-TT11-6.8B
D312 8-719-978-33 DIODE DTZ-TT11-6.8B
D313 8-719-978-33 DIODE DTZ-TT11-6.8B
< IC >
IC101 8-752-392-04 IC CXD2598Q
IC201 8-752-921-24 IC CXP740056-010R
IC203 8-759-660-38 IC BR24C16FJ-E2
IC301 8-759-527-33 IC LB1930M-TLM
IC303 8-759-363-81 IC XC61AN4002PR
IC304 8-759-655-30 IC NJM2395F08
IC305 8-759-655-29 IC NJM2395F05
IC401 8-759-662-11 IC TLV2362IPWR
< COIL >
L140 1-412-058-11 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q201 8-729-020-67 TRANSISTOR XN1A312-TX
Q231 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q232 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q301 8-729-028-62 TRANSISTOR DTA115EKA-T146
Q302 8-729-230-49 TRANSISTOR 2SC2712-YG
Q303 8-729-921-12 TRANSISTOR 2SD1834
Q401 8-729-901-00 TRANSISTOR DTC124EK
Q402 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q410 8-729-015-39 TRANSISTOR DTC323TK
Q420 8-729-015-39 TRANSISTOR DTC323TK
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/16W
R111 1-216-833-11 METAL CHIP 10K 5% 1/16W
R112 1-216-845-11 METAL CHIP 100K 5% 1/16W
R114 1-216-833-11 METAL CHIP 10K 5% 1/16W
R115 1-216-833-11 METAL CHIP 10K 5% 1/16W
R116 1-216-837-11 METAL CHIP 22K 5% 1/16W
R117 1-216-845-11 METAL CHIP 100K 5% 1/16W
R120 1-216-839-11 METAL CHIP 33K 5% 1/16W
R121 1-216-845-11 METAL CHIP 100K 5% 1/16W
R122 1-216-845-11 METAL CHIP 100K 5% 1/16W
R123 1-216-833-11 METAL CHIP 10K 5% 1/16W
R124 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R125 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R126 1-216-857-11 METAL CHIP 1M 5% 1/16W
R140 1-216-834-11 METAL CHIP 12K 5% 1/16W
R141 1-216-834-11 METAL CHIP 12K 5% 1/16W
R142 1-216-834-11 METAL CHIP 12K 5% 1/16W
R143 1-216-834-11 METAL CHIP 12K 5% 1/16W
R144 1-216-834-11 METAL CHIP 12K 5% 1/16W
R145 1-216-834-11 METAL CHIP 12K 5% 1/16W
R146 1-216-833-11 METAL CHIP 10K 5% 1/16W
R147 1-216-833-11 METAL CHIP 10K 5% 1/16W
R201 1-216-821-11 METAL CHIP 1K 5% 1/16W
R202 1-216-845-11 METAL CHIP 100K 5% 1/16W
R203 1-216-841-11 METAL CHIP 47K 5% 1/16W
R207 1-216-845-11 METAL CHIP 100K 5% 1/16W
R209 1-216-833-11 METAL CHIP 10K 5% 1/16W
R220 1-216-864-11 METAL CHIP 0 5% 1/16W
R221 1-216-864-11 METAL CHIP 0 5% 1/16W
R232 1-216-845-11 METAL CHIP 100K 5% 1/16W
R233 1-216-833-11 METAL CHIP 10K 5% 1/16W
R234 1-216-821-11 METAL CHIP 1K 5% 1/16W
R252 1-216-845-11 METAL CHIP 100K 5% 1/16W
R253 1-216-845-11 METAL CHIP 100K 5% 1/16W
R254 1-216-845-11 METAL CHIP 100K 5% 1/16W
R302 1-216-845-11 METAL CHIP 100K 5% 1/16W
R303 1-216-846-11 METAL CHIP 120K 5% 1/16W
R304 1-216-847-11 METAL CHIP 150K 5% 1/16W
R305 1-216-841-11 METAL CHIP 47K 5% 1/16W
R306 1-216-844-11 METAL CHIP 82K 5% 1/16W
R311 1-216-841-11 METAL CHIP 47K 5% 1/16W
R315 1-216-864-11 METAL CHIP 0 5% 1/16W
R401 1-216-833-11 METAL CHIP 10K 5% 1/16W
R402 1-216-833-11 METAL CHIP 10K 5% 1/16W
R403 1-216-833-11 METAL CHIP 10K 5% 1/16W
R404 1-216-833-11 METAL CHIP 10K 5% 1/16W
R405 1-216-833-11 METAL CHIP 10K 5% 1/16W
R406 1-216-833-11 METAL CHIP 10K 5% 1/16W
R407 1-216-833-11 METAL CHIP 10K 5% 1/16W
R408 1-216-833-11 METAL CHIP 10K 5% 1/16W
R411 1-216-813-11 METAL CHIP 220 5% 1/16W
R412 1-216-813-11 METAL CHIP 220 5% 1/16W
R413 1-216-845-11 METAL CHIP 100K 5% 1/16W
R414 1-216-845-11 METAL CHIP 100K 5% 1/16W
R415 1-216-864-11 METAL CHIP 0 5% 1/16W
R416 1-216-864-11 METAL CHIP 0 5% 1/16W
R420 1-216-864-11 METAL CHIP 0 5% 1/16W
< VARIABLE RESISTOR >
RV201 1-223-834-11 RES, ADJ, CARBON 47K
MAIN
