Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< SWITCH >
SW201 1-529-565-41 SWITCH, PUSH (1 KEY) (MAGAZINE DETECT)
< VIBRATOR >
X130 1-760-307-11 VIBRATOR, CERAMIC (16.9344MHz)
X201 1-579-126-11 VIBRATOR, CERAMIC (12MHz)
**************************************************************
* A-3326-000-A RF BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C106 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C107 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C108 1-124-779-00 ELECT CHIP 10uF 20% 16V
C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C111 1-124-779-00 ELECT CHIP 10uF 20% 16V
C201 1-117-681-11 ELECT CHIP 100uF 20% 16V
C202 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C203 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C204 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C205 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C206 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C207 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C208 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C209 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C217 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN102 1-778-303-21 CONNECTOR, FPC (ZIF) 16P
CNJ101 1-778-777-21 CONNECTOR, FPC 26P
< IC >
IC101 8-752-095-36 IC CXA2596M-T6
IC201 8-759-832-99 IC LA6576L-TE-L
< TRANSISTOR >
Q101 8-729-141-48 TRANSISTOR 2SB624-BV345
< RESISTOR >
R101 1-216-847-11 METAL CHIP 150K 5% 1/16W
R102 1-216-847-11 METAL CHIP 150K 5% 1/16W
R103 1-216-864-11 METAL CHIP 0 5% 1/16W
R104 1-216-158-00 RES-CHIP 22 5% 1/8W
R105 1-216-857-11 METAL CHIP 1M 5% 1/16W
R106 1-216-857-11 METAL CHIP 1M 5% 1/16W
R107 1-216-864-11 METAL CHIP 0 5% 1/16W
R108 1-216-845-11 METAL CHIP 100K 5% 1/16W
R109 1-216-837-11 METAL CHIP 22K 5% 1/16W
R110 1-216-821-11 METAL CHIP 1K 5% 1/16W
R201 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R202 1-216-833-11 METAL CHIP 10K 5% 1/16W
R203 1-216-833-11 METAL CHIP 10K 5% 1/16W
R204 1-216-842-11 METAL CHIP 56K 5% 1/16W
R205 1-216-833-11 METAL CHIP 10K 5% 1/16W
R206 1-216-842-11 METAL CHIP 56K 5% 1/16W
R207 1-216-833-11 METAL CHIP 10K 5% 1/16W
R208 1-216-842-11 METAL CHIP 56K 5% 1/16W
R209 1-216-833-11 METAL CHIP 10K 5% 1/16W
R210 1-216-842-11 METAL CHIP 56K 5% 1/16W
R211 1-216-833-11 METAL CHIP 10K 5% 1/16W
R212 1-216-839-11 METAL CHIP 33K 5% 1/16W
R213 1-216-833-11 METAL CHIP 10K 5% 1/16W
R214 1-216-839-11 METAL CHIP 33K 5% 1/16W
R215 1-216-839-11 METAL CHIP 33K 5% 1/16W
R216 1-216-842-11 METAL CHIP 56K 5% 1/16W
R218 1-216-839-11 METAL CHIP 33K 5% 1/16W
R219 1-216-843-11 METAL CHIP 68K 5% 1/16W
R220 1-216-834-11 METAL CHIP 12K 5% 1/16W
R222 1-216-821-11 METAL CHIP 1K 5% 1/16W
R223 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
SW1 1-529-566-41 SWITCH, PUSH (1 KEY)
(CHUKING END DETECT)
SW2 1-529-566-41 SWITCH, PUSH (1 KEY) (SAVE END DETECT)
**************************************************************
* 1-676-722-12 SW BOARD
*********
< SWITCH >
SW301 1-571-532-21 SWITCH, TACTIL (Z)
SW302 1-571-532-21 SWITCH, TACTIL (RESET)
**************************************************************
MISCELLANEOUS
**************
5 1-792-043-11 CORD (WITH CONNECTOR) (POWER)
6 A-3301-964-A RELAY BOX ASSY
7 1-792-045-21 CORD (WITH CONNECTOR) (ANT-OUT)
(for RELAY BOX ASSY)
8 1-792-044-21 CORD (WITH CONNECTOR) (CD-OUT)
(for RELAY BOX ASSY)
9 A-3220-786-A ROTARY COMMANDER (RM-X80RF)
10 1-792-596-11 CABLE (WITH CONNECTOR) (for RM-X80RF)
56 1-676-735-11 FM FLEXIBLE BOARD
68 1-676-339-11 MAIN FLEXIBLE BOARD
251 1-676-341-11 OP FLEXIBLE BOARD
0255 8-820-103-05 OPTICAL PICK-UP KSS-720A/Q-RP
F1 1-532-798-11 FUSE (BLADE TYPE) (AUTO FUSE) (1A/32V)
F2 1-532-731-11 FUSE (BLADE TYPE) (AUTO FUSE) (3A/32V)
M101 A-3315-151-A SLED MOTOR ASSY (251)
M102 A-3301-998-A SPINDLE MOTOR (S) SUB ASSY
M103 A-3301-123-A ELJ MOTOR ASSY (CHUCKING)
M104 A-3301-123-A ELJ MOTOR ASSY (ELEVATOR)
RV202 1-227-137-11 RES, VAR, SLIDE 10K
(ELEVATOR HEIGHT SENSOR)
************************************************************
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
