Sony CDX-GT06 Service Manual

12
CDX-GT06/CXS-GT06HP
2-10. SERVO BOARD
2-9. LE MOTOR ASSY (M903)
3
qs
2
gear (LE1)
6 leaf spring (LE)
4
lever (D)
bracket (LEM-N)
slider (R)
5 screw
(+P 1.7
× 2.2)
7 screw
(+M 1.7
× 2.5)
0 screw
(+M 1.7
× 2.5)
qd two toothed lock screws
(+M 1.4
)
qa screw
(+M 1.7
× 2.5)
8 bearing (LEB-N)
9 gear (LE) assy
qf LE motor assy
(M903)
1 Remove the two solders.
5 claw
6 SERVO board
4 toothed lock screw
(M 1.7
× 2.5)
1 Remove the eight solders.
2 Remove the three solders.
3 optical pick-up (16 core)
(CN2)

Sony CDX-GT06 Specifications

General

Brand	Sony
Model	CDX-GT06
Category	Car Receiver
Language	English
