CDX-GT06/CXS-GT06HP
2-4. CHASSIS (T) SUB ASSY
2-3. MAIN BOARD
3
MAIN board
2
two
screws
(+PTT 2.6
×
8
)
1
three
screws
(+BTT 2.6
×
5)
5
SENSOR board
6
chassis (T) sub ass
y
4
claw
3
claw
1
two
screws
(+P 1.7
×
2.2)
2
two
screws
(+P 1.7
×
2.2)
