CDX-GT35U/GT39U/GT39UE
10
3-5. CHASSIS (T) SUB ASSY
3-6. ROLLER ARM ASSY
4 chassis (T) sub assy
3 claw
1 two screws
(M 1.7 u 2.5)
2 two screws
(M 1.7 u 2.5)
3 washer
4 gear (RA1)
6 roller arm assy
5
1 spring (RAL)
2 spring (RAR)
