31
CDX-GT35U/GT39U/GT39UE
SECTION 6
ELECTRICAL PARTS LIST
JACK BOARD
**********
< FERRITE BEAD >
FB901 1-414-760-21 INDUCTOR, FERRITE BEAD
FB902 1-414-760-21 INDUCTOR, FERRITE BEAD
FB903 1-414-760-21 INDUCTOR, FERRITE BEAD
< JACK >
J901 1-819-732-11 JACK (DIA. 3.5) (AUX)
*************************************************************
KEY BOARD
*********
1-780-659-21 CONNECTOR (RUBBER)
4-157-873-02 ILLUMINATOR (LCD)
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C902 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C906 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-820-619-11 PLUG, CONNECTOR 20P
CN902 1-820-858-21 CONNECTOR, USB (SOCKET) 4P (USB)
< DIODE >
D901 6-501-193-01 DIODE 1SS355WTE-17
D902 6-501-730-01 DIODE MAZ8051GMLS0
D906 6-501-782-01 DIODE MAZ8180GMLS0
D907 6-501-743-01 DIODE MAZ8068GMLS0
D908 6-501-743-01 DIODE MAZ8068GMLS0
D909 6-501-743-01 DIODE MAZ8068GMLS0
D910 6-501-743-01 DIODE MAZ8068GMLS0
D911 6-501-743-01 DIODE MAZ8068GMLS0
D912 6-501-743-01 DIODE MAZ8068GMLS0
< IC >
IC901 6-714-396-01 IC LC75829PWH-US-H
IC902 6-600-629-01 IC RS-470 (IR)
< COIL >
L901 1-457-223-11 COIL, COMMON MODE CHOKE
< LIQUID CRYSTAL DISPLAY >
LCD901 1-802-991-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 6-501-339-01 LED NESW505CT-AST (LCD BACK LIGHT)
LED907 6-502-875-01 LED SML-310PTT86TK (OFF) (GT39U/GT39UE)
LED907 6-502-877-01 LED SML-310VTT86TJ (OFF) (GT35U)
LED911 6-502-875-01 LED SML-310PTT86TK (SOURCE)
(GT39U/GT39UE)
LED911 6-502-877-01 LED SML-310VTT86TJ (SOURCE) (GT35U)
LED913 6-502-875-01 LED SML-310PTT86TK (SOURCE)
(GT39U/GT39UE)
LED913 6-502-877-01 LED SML-310VTT86TJ (SOURCE) (GT35U)
LED914 6-502-875-01 LED SML-310PTT86TK (SEEK+ > M)
(GT39U/GT39UE)
LED914 6-502-877-01 LED SML-310VTT86TJ (SEEK+ > M)
(GT35U)
LED915 6-502-875-01 LED SML-310PTT86TK ( ) (GT39U/GT39UE)
LED915 6-502-877-01 LED SML-310VTT86TJ ( ) (GT35U)
LED918 6-502-875-01 LED SML-310PTT86TK (MODE)
(GT39U/GT39UE)
LED918 6-502-877-01 LED SML-310VTT86TJ (MODE) (GT35U)
LED924 6-502-875-01 LED SML-310PTT86TK (MODE)
(GT39U/GT39UE)
LED924 6-502-877-01 LED SML-310VTT86TJ (MODE) (GT35U)
LED925 6-502-875-01 LED SML-310PTT86TK ( ) (GT39U/GT39UE)
LED925 6-502-877-01 LED SML-310VTT86TJ ( ) (GT35U)
LED930 6-502-875-01 LED SML-310PTT86TK ( ) (GT39U/GT39UE)
LED930 6-502-877-01 LED SML-310VTT86TJ ( ) (GT35U)
LED931 6-502-875-01 LED SML-310PTT86TK (m . SEEK–)
(GT39U/GT39UE)
LED931 6-502-877-01 LED SML-310VTT86TJ (m . SEEK–)
(GT35U)
< SWITCH >
LSW901 1-786-805-13 SWITCH, TACTILE (WITH LED) (Z) (GT35U)
LSW901 1-786-806-13 SWITCH, TACTILE (WITH LED) (Z)
(GT39U/GT39UE)
LSW905 1-786-805-13 SWITCH, TACTILE (WITH LED) (DSPL/SCRL)
(GT35U)
LSW905 1-786-806-13 SWITCH, TACTILE (WITH LED) (DSPL/SCRL)
(GT39U/GT39UE)
LSW906 1-786-805-13 SWITCH, TACTILE (WITH LED) (6/PAUSE)
(GT35U)
LSW906 1-786-806-13 SWITCH, TACTILE (WITH LED) (6/PAUSE)
(GT39U/GT39UE)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JACK
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
KEY
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
• Abbreviation
RU : Russian model
AR : Argentina model
Ver. 1.1
