Sony CDX-GT35UW Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
30
CDX-GT35UW
R921 1-216-821-11 METAL CHIP 1K 5% 1/10W
R922 1-216-821-11 METAL CHIP 1K 5% 1/10W
R923 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R924 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R925 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R926 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R927 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R928 1-216-820-11 METAL CHIP 820 5% 1/10W
R929 1-216-821-11 METAL CHIP 1K 5% 1/10W
R930 1-216-821-11 METAL CHIP 1K 5% 1/10W
R931 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R932 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R933 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R934 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R935 1-216-812-11 METAL CHIP 180 5% 1/10W
R936 1-216-029-00 METAL CHIP 150 5% 1/10W
R939 1-216-033-00 METAL CHIP 220 5% 1/10W
R940 1-216-031-00 METAL CHIP 180 5% 1/10W
R943 1-216-025-11 METAL CHIP 100 5% 1/10W
R944 1-216-025-11 METAL CHIP 100 5% 1/10W
R947 1-216-033-00 METAL CHIP 220 5% 1/10W
R948 1-216-031-00 METAL CHIP 180 5% 1/10W
R951 1-216-033-00 METAL CHIP 220 5% 1/10W
R952 1-216-031-00 METAL CHIP 180 5% 1/10W
R955 1-216-809-11 METAL CHIP 100 5% 1/10W
R959 1-216-809-11 METAL CHIP 100 5% 1/10W
R963 1-216-809-11 METAL CHIP 100 5% 1/10W
R964 1-216-809-11 METAL CHIP 100 5% 1/10W
R967 1-216-809-11 METAL CHIP 100 5% 1/10W
R968 1-216-025-11 METAL CHIP 100 5% 1/10W
R986 1-216-864-11 SHORT CHIP 0
R987 1-216-864-11 SHORT CHIP 0
R988 1-216-809-11 METAL CHIP 100 5% 1/10W
R989 1-216-809-11 METAL CHIP 100 5% 1/10W
R990 1-216-809-11 METAL CHIP 100 5% 1/10W
R991 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R992 1-216-833-11 METAL CHIP 10K 5% 1/10W
R993 1-216-833-11 METAL CHIP 10K 5% 1/10W
R996 1-216-833-11 METAL CHIP 10K 5% 1/10W
R998 1-216-864-11 SHORT CHIP 0
< NETWORK RESISTOR >
RB901 1-239-662-81 RESISTOR, NETWORK 10X2
< ROTARY ENCODER >
RE901 1-479-902-32 ENCODER, ROTARY
(PUSH ENTER/SELECT,VOLUME)
< SWITCH >
S902 1-786-653-21 SWITCH, TACTILE (
m .
SEEK-)
S903 1-786-653-21 SWITCH, TACTILE (
)
S904 1-786-653-21 SWITCH, TACTILE (MODE)
S905 1-786-653-21 SWITCH, TACTILE (SEEK+
> M
)
S906 1-786-653-21 SWITCH, TACTILE (SOURCE)
S907 1-786-653-21 SWITCH, TACTILE (OFF)
S908 1-786-653-21 SWITCH, TACTILE (
)
< VARISTOR >
VDR900 1-804-988-21 VARISTOR, CHIP (1608)
VDR901 1-804-988-21 VARISTOR, CHIP (1608)
VDR903 1-804-988-21 VARISTOR, CHIP (1608)
VDR906 1-804-988-21 VARISTOR, CHIP (1608)
VDR908 1-804-988-21 VARISTOR, CHIP (1608)
*************************************************************
A-1785-108-A MAIN BOARD, COMPLETE
********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C5 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C6 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C8 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C9 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C12 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C13 1-100-742-91 CERAMIC CHIP 2.2uF 20% 10V
C16 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C18 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C19 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C20 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C21 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C25 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C28 1-126-947-11 ELECT 47uF 20% 35V
C101 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C103 1-126-961-11 ELECT 2.2uF 20% 50V
C104 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-964-11 ELECT 10uF 20% 50V
C107 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C108 1-126-964-11 ELECT 10uF 20% 50V
C109 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C110 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C111 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C112 1-126-964-11 ELECT 10uF 20% 50V
C113 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C114 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C115 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C116 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C201 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C203 1-126-961-11 ELECT 2.2uF 20% 50V
C204 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C205 1-126-960-11 ELECT 1uF 20% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C210 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C211 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C212 1-126-964-11 ELECT 10uF 20% 50V
C213 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C214 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C215 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
KEY MAIN
