Sony CDX-GT35UW Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3131
CDX-GT35UW
C217 1-126-964-11 ELECT 10uF 20% 50V
C301 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C303 1-128-551-11 ELECT 22uF 20% 63V
C304 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C305 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C306 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C307 1-124-589-11 ELECT 47uF 20% 16V
C308 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-124-233-11 ELECT 10uF 20% 16V
C311 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C312 1-124-233-11 ELECT 10uF 20% 16V
C313 1-124-233-11 ELECT 10uF 20% 16V
C314 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C315 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-126-934-11 ELECT 220uF 20% 16V
C318 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C319 1-126-964-11 ELECT 10uF 20% 50V
C322 1-126-947-11 ELECT 47uF 20% 35V
C323 1-126-961-11 ELECT 2.2uF 20% 50V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C403 1-128-057-11 ELECT 330uF 20% 6.3V
C404 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C405 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C406 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C409 1-126-926-11 ELECT 1000uF 20% 10V
C411 1-126-924-11 ELECT 330uF 20% 10V
C413 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C420 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C421 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C422 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C425 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C427 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C428 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C429 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C433 1-124-589-11 ELECT 47uF 20% 16V
C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C435 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C436 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C501 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C502 1-165-727-31 ELECT 120uF 20% 16V
C503 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C505 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C506 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C507 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C508 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C509 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-126-924-11 ELECT 330uF 20% 10V
C516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C518 1-126-934-11 ELECT 220uF 20% 16V
C519 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C520 1-124-584-00 ELECT 100uF 20% 10V
C521 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C523 1-104-665-11 ELECT 100uF 20% 25V
C524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-124-584-00 ELECT 100uF 20% 10V
C702 1-124-234-00 ELECT 22uF 20% 16V
C703 1-124-233-11 ELECT 10uF 20% 16V
C704 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C705 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C706 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C707 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C804 1-100-385-91 CERAMIC CHIP 0.47uF 25V
C805 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C806 1-163-009-91 CERAMIC CHIP 0.001uF 10% 50V
C807 1-112-302-11 ELECT 3300uF 20% 16V
C808 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C810 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C811 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C812 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C813 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN403 1-820-622-21 SOCKET, CONNECTOR 20P
CN501 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN701 1-820-611-11 CONNECTOR, BOARD TO BOARD 28P
CN802 1-774-701-21 PIN, CONNECTOR 16P
< DIODE >
D101 1-805-043-11 ABSORBER, CHIP SURGE
D104 6-502-643-01 DIODE 1A4-A2
D105 6-502-643-01 DIODE 1A4-A2
D201 1-805-043-11 ABSORBER, CHIP SURGE
D204 6-502-643-01 DIODE 1A4-A2
D205 6-502-643-01 DIODE 1A4-A2
D301 8-719-069-57 DIODE UDZSUSTE-176.8B
D302 6-502-643-01 DIODE 1A4-A2
D303 6-502-643-01 DIODE 1A4-A2
D304 6-502-643-01 DIODE 1A4-A2
D305 6-502-643-01 DIODE 1A4-A2
D306 6-501-817-01 DIODE MA2J1110GLS0
D308 6-501-817-01 DIODE MA2J1110GLS0
D309 6-501-817-01 DIODE MA2J1110GLS0
D401 6-502-131-01 DIODE LRB751V-40T1G
D403 6-501-743-01 DIODE MAZ8068GMLS0
D404 6-501-743-01 DIODE MAZ8068GMLS0
D410 6-501-743-01 DIODE MAZ8068GMLS0
D411 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
D502 6-501-817-01 DIODE MA2J1110GLS0
D503 6-501-768-01 DIODE MAZ8120GMLS0
D504 6-501-657-01 DIODE MA24D5000BS0
D505 6-501-734-01 DIODE MAZ8056GMLS0
D510 6-501-718-01 DIODE MAZ8039GLLS0
D511 6-501-817-01 DIODE MA2J1110GLS0
D512 6-501-817-01 DIODE MA2J1110GLS0
D701 6-501-656-01 DIODE LBAT54ALT1G
D806 6-501-747-01 DIODE MAZ8075GMLS0
