Sony CDX-GT71W Service Manual

19
CDX-GT71W/GT710/GT760
3-6. SERVO BOARD
3-5. MAIN BOARD
1 three ground point screws
(+PTT 2.6
× 6)
2 two screws
(+PTT 2.6
× 8)
8 screw
(+PTT 2.6
× 10)
0 two screws
(+PTT 2.6
× 12)
qa two screws
(+PTT 2.6
× 10)
qs screw
(+PTT 2.6
× 10)
qd heat sink
9 two screws
(+P 2.6
× 8)
6 screw
(+PTT 2.6
× 8)
7 cord (automobile)
4 MAIN board
5 CN401 (3P)
3 insulating sheet
5 SERVO board
SERVO board
claw
claw
3 toothed lock screw
(M 1.7 × 2.5)
2 toothed lock screw
(M 1.7 × 2.5)
1 Remove the eleven solders.
GRY
YEL
BLU
ORG
RED
BLK
RED
WHT
BLK
RED
WHT
4 optical pick-up (16 core
)
(CN1)
