50
CDX-GT71W/GT710/GT760
SECTION 7
ELECTRICAL PARTS LIST
AUX BOARD
**********
< JACK >
J991 1-820-664-11 SMALL TYPE JACK (WITH SWITCH) (AUX)
< FERRITE BEAD >
R1 1-500-329-21 INDUCTOR, FERRITE BEAD
R2 1-500-329-21 INDUCTOR, FERRITE BEAD
R3 1-500-329-21 INDUCTOR, FERRITE BEAD
*************************************************************
BASE PANEL BOARD
*****************
< CONNECTOR >
CN904 1-820-630-11 SOCKET, CONNECTOR 24P
CN905 1-818-076-71 CONNECTOR, FFC/FPC (ZIF) 36P
< SWITCH >
S901 1-798-032-11 SWITCH, DETECTION (NOSE DET)
S902 1-786-653-21 SWITCH, TACTILE (RESET)
*************************************************************
DISPLAY BOARD
**************
< CAPACITOR >
C901 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C903 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C904 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C910 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C914 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C915 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C916 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C919 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C923 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C925 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C956 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C957 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C958 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C981 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN902 1-820-620-11 PLUG, CONNECTOR 24P
< DIODE >
D931 8-719-420-90 DIODE MA8051-M
D932 8-719-420-90 DIODE MA8051-M
D933 8-719-420-90 DIODE MA8051-M
D934 8-719-420-90 DIODE MA8051-M
D935 8-719-420-90 DIODE MA8051-M
D936 8-719-420-90 DIODE MA8051-M
D937 8-719-420-90 DIODE MA8051-M
D938 8-719-420-90 DIODE MA8051-M
D951 8-719-420-90 DIODE MA8051-M
D952 1-803-902-21 PROTECTOR CHIP, SURGE
D953 1-803-902-21 PROTECTOR CHIP, SURGE
D954 1-803-902-21 PROTECTOR CHIP, SURGE
D955 8-719-420-90 DIODE MA8051-M
D956 8-719-420-90 DIODE MA8051-M
< RESISTOR >
FB901 1-216-809-11 METAL CHIP 100 5% 1/10W
FB902 1-216-809-11 METAL CHIP 100 5% 1/10W
FB903 1-216-809-11 METAL CHIP 100 5% 1/10W
FB904 1-216-864-11 SHORT CHIP 0
FB905 1-216-809-11 METAL CHIP 100 5% 1/10W
FB908 1-216-809-11 METAL CHIP 100 5% 1/10W
FB911 1-216-864-11 SHORT CHIP 0
FB912 1-216-809-11 METAL CHIP 100 5% 1/10W
FB913 1-216-809-11 METAL CHIP 100 5% 1/10W
FB914 1-216-809-11 METAL CHIP 100 5% 1/10W
FB915 1-216-809-11 METAL CHIP 100 5% 1/10W
FB916 1-216-809-11 METAL CHIP 100 5% 1/10W
FB917 1-216-864-11 SHORT CHIP 0
FB918 1-216-864-11 SHORT CHIP 0
FB919 1-216-864-11 SHORT CHIP 0
FB920 1-216-809-11 METAL CHIP 100 5% 1/10W
FB921 1-216-809-11 METAL CHIP 100 5% 1/10W
FB922 1-216-864-11 SHORT CHIP 0
FB923 1-216-864-11 SHORT CHIP 0
< VACUUM FLUORESCENT DISPLAY >
FL900 1-519-842-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC901 6-710-864-01 IC M30876FJBA01GP
IC903 6-600-163-01 IC RS-770 (IR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
•Abbreviation
CND : Canadian model
CH : Chinese model
MX : Mexican model
IND : Indian model
DISPLAYBASE PANELAUX
Ver. 1.2
