CDX-GT71W/GT710/GT760
< JUMPER RESISTOR >
JC902 1-216-864-11 SHORT CHIP 0
JC907 1-216-864-11 SHORT CHIP 0
JR921 1-216-864-11 SHORT CHIP 0
JR925 1-216-864-11 SHORT CHIP 0
< DIODE >
LED920 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
LED922 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
LED923 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
LED924 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
LED926 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
LED927 6-501-376-01 LED SO-194S-WM-SD-T
(RING ILLUMINATION)
< SWITCH >
LSW901 1-798-019-11 SWITCH, TACTILE (WITH LED) (SEEK+ >)
LSW902 1-798-019-11 SWITCH, TACTILE (WITH LED) (SEEK– .)
LSW903 1-798-019-11 SWITCH, TACTILE (WITH LED) (DSPL)
(EXCEPT GT710:AEP,UK)
LSW903 1-798-019-11 SWITCH, TACTILE (WITH LED) (DSPL/PTY)
(GT710:AEP,UK)
LSW904 1-798-019-11 SWITCH, TACTILE (WITH LED) (LIST)
LSW905 1-798-019-11 SWITCH, TACTILE (WITH LED) (IMAGE)
LSW906 1-798-019-11 SWITCH, TACTILE (WITH LED) (MENU)
LSW907 1-798-019-11 SWITCH, TACTILE (WITH LED) (6/PAUSE)
LSW908 1-798-019-11 SWITCH, TACTILE (WITH LED) (5/BBE MP)
LSW909 1-798-019-11 SWITCH, TACTILE (WITH LED) (4/GP/ALBM +)
LSW910 1-798-019-11 SWITCH, TACTILE (WITH LED) (3/GP/ALBM –)
LSW911 1-798-019-11 SWITCH, TACTILE (WITH LED) (2/SHUF)
LSW912 1-798-019-11 SWITCH, TACTILE (WITH LED) (1/REP)
LSW913 1-798-019-11 SWITCH, TACTILE (WITH LED) (SCRL)
(EXCEPT GT710:AEP,UK)
LSW913 1-798-019-11 SWITCH, TACTILE (WITH LED) (AF/TA)
(GT710:AEP,UK)
LSW914 1-798-019-11 SWITCH, TACTILE (WITH LED) (OFF)
LSW915 1-798-019-11 SWITCH, TACTILE (WITH LED) (Z/ANGLE)
< TRANSISTOR >
Q920 6-550-752-01 TRANSISTOR DTC614TKT146
Q921 6-550-752-01 TRANSISTOR DTC614TKT146
Q922 6-550-752-01 TRANSISTOR DTC614TKT146
< RESISTOR >
R901 1-216-820-11 METAL CHIP 820 5% 1/10W
R902 1-216-821-11 METAL CHIP 1K 5% 1/10W
R903 1-216-821-11 METAL CHIP 1K 5% 1/10W
R904 1-216-821-11 METAL CHIP 1K 5% 1/10W
R905 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R907 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R908 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R909 1-216-820-11 METAL CHIP 820 5% 1/10W
R910 1-216-821-11 METAL CHIP 1K 5% 1/10W
R911 1-216-820-11 METAL CHIP 820 5% 1/10W
R912 1-216-821-11 METAL CHIP 1K 5% 1/10W
R913 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R914 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R915 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R916 1-216-845-11 METAL CHIP 100K 5% 1/10W
R917 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R918 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R919 1-216-864-11 SHORT CHIP 0
R920 1-216-820-11 METAL CHIP 820 5% 1/10W
R921 1-216-819-11 METAL CHIP 680 5% 1/10W
R922 1-216-818-11 METAL CHIP 560 5% 1/10W
R923 1-216-817-11 METAL CHIP 470 5% 1/10W
R924 1-216-818-11 METAL CHIP 560 5% 1/10W
R925 1-216-817-11 METAL CHIP 470 5% 1/10W
R926 1-216-818-11 METAL CHIP 560 5% 1/10W
R927 1-216-817-11 METAL CHIP 470 5% 1/10W
R928 1-216-818-11 METAL CHIP 560 5% 1/10W
R929 1-216-817-11 METAL CHIP 470 5% 1/10W
R931 1-216-814-11 METAL CHIP 270 5% 1/10W
R932 1-216-814-11 METAL CHIP 270 5% 1/10W
R933 1-216-814-11 METAL CHIP 270 5% 1/10W
R934 1-216-814-11 METAL CHIP 270 5% 1/10W
R936 1-216-815-11 METAL CHIP 330 5% 1/10W
R937 1-216-864-11 SHORT CHIP 0
R938 1-216-864-11 SHORT CHIP 0
R939 1-216-864-11 SHORT CHIP 0
R940 1-216-864-11 SHORT CHIP 0
R941 1-216-818-11 METAL CHIP 560 5% 1/10W
R942 1-216-814-11 METAL CHIP 270 5% 1/10W
R944 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R945 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R946 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R948 1-216-864-11 SHORT CHIP 0
R949 1-216-864-11 SHORT CHIP 0
R950 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R951 1-216-845-11 METAL CHIP 100K 5% 1/10W
R952 1-216-845-11 METAL CHIP 100K 5% 1/10W
R953 1-216-845-11 METAL CHIP 100K 5% 1/10W
R954 1-216-833-11 METAL CHIP 10K 5% 1/10W
R955 1-216-833-11 METAL CHIP 10K 5% 1/10W
R956 1-216-809-11 METAL CHIP 100 5% 1/10W
R958 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R959 1-216-845-11 METAL CHIP 100K 5% 1/10W
R960 1-216-845-11 METAL CHIP 100K 5% 1/10W
R961 1-216-845-11 METAL CHIP 100K 5% 1/10W
R962 1-216-845-11 METAL CHIP 100K 5% 1/10W
R963 1-216-017-11 RES-CHIP 47 5% 1/10W
R964 1-216-017-11 RES-CHIP 47 5% 1/10W
R965 1-216-864-11 SHORT CHIP 0
R981 1-216-813-11 METAL CHIP 220 5% 1/10W
R982 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S903 1-786-653-21 SWITCH, TACTILE (SOURCE)
S904 1-786-653-21 SWITCH, TACTILE (MODE)
S906 1-479-942-11 ENCODER, ROTARY (PUSH SOUND/ENTER,
VOLUME)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
