21
CDX-GT71W/GT710/GT760
3-9. CHASSIS (OP) ASSY
7
coil spring (damper) (natural)
8
coil spring (damper) (green
)
6
chassis (OP) assy
5
1
tension spring (KF)
2
gear (LE1)
3
lever (D)
4
slider (R)
Ver. 1.2
