– 11 –
3-9. CD MECHANISM BLOCK
3-10. TAPE MECHANISM BLOCK
1
screws (2.6x10)
2
screws (2.6x10)
3
CD mechanism block
1
screws +BVTP 3x10
2
screw +BVTP 3x1
0
3
tape mechanism block
wiring stopper
