– 8 –
3-3. WIRES
3-4. TRANSFORMER, POWER
CABINET (REAR
)
FRONT CABINE
T
A
B
C
D
E
F
1
screws +BVTP 3x10
2
screws +BVTP 3x10
3
screws +BVTP 3x10
4
transformer, power
6
CNP901
5
CNP902
Put flat cable and wires between the cabinets and push them in the
grooves located at A to F in the figure to prevent disconnection
before assembling the set.
