22
CFM-20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C133 1-126-934-11 ELECT 220uF 20% 10V
C134 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C135 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C136 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
<FILTER>
CF1 1-795-079-71 FILTER, CERAMIC
CF2 1-781-790-11 FILTER, AM CERAMIC
<CONNECTOR>
* CNP101 1-785-669-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP102 1-785-670-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP103 1-785-668-11 PIN, CONNECTOR (PC BOARD) 2P
<TRIMMER CAPACITOR>
CT1 1-141-645-11 CAP, VAR (FM FREQUENCY COVERAGE)
CT2 1-141-645-11 CAP, VAR (FM TRACKING)
CT3 1-141-645-11 CAP, VAR (AM FREQUENCY COVERAGE)
CT4 1-141-645-11 CAP, VAR (AM TRACKING)
<VARIABLE CAPACITOR>
CV1 1-141-645-11 CAP, VAR (TUNING)
CV2 1-141-645-11 CAP, VAR (TUNING)
CV3 1-141-645-11 CAP, VAR (TUNING)
CV4 1-141-645-11 CAP, VAR (TUNING)
<DIODE>
D1 8-719-991-33 DIODE 1SS133T-77
D2 8-719-991-33 DIODE 1SS133T-77
D101 8-719-109-72 DIODE RD3.9ESB2
D102 8-719-991-33 DIODE 1SS133T-77
D103 8-719-991-33 DIODE 1SS133T-77
D104 8-719-059-97 LED L-34HD (OPR/BATT)
(AEP,UK,IT,CET,AR,HK,SP)
D106 8-719-991-33 DIODE 1SS133T-77
D107 8-719-991-33 DIODE 1SS133T-77
D108 8-719-991-33 DIODE 1SS133T-77
<IC>
IC1 8-759-697-57 IC TA2132AF(EL)
IC101 8-759-467-54 IC MM1315BD
<JUMPER RESISTOR>
JC1 1-216-864-91 SHORT 0
JC2 1-216-864-91 SHORT 0
JC3 1-216-864-91 SHORT 0
(AEP,UK,CET,C&SA,AR,HK,MX,SP,TW)
JC4 1-216-864-91 SHORT 0
JC101 1-216-864-91 SHORT 0
<CABLE HOLDER>
* KH101 1-573-287-11 HOLDER, CABLE 2P
* KH102 1-573-287-11 HOLDER, CABLE 2P
<COIL>
L1 1-409-775-21 COIL, AIR-CORE (FM RF) (FM TRACKING)
L2 1-422-230-11 COIL, AIR-CORE (FM OSC)
(FM FREQUENCY COVERAGE)
(C&SA,AR,HK,MX,SP,TW)
L2 1-424-726-11 COIL, AIR-CORE (FM OSC)
(FM FREQUENCY COVERAGE)(AEP,UK,CET)
L2 1-419-998-11 COIL, OSCILLATION (FM OSC)
(FM FREQUENCY COVERAGE)(IT)
L3 1-501-919-11 ANTENNA, FERRITE-BAR (AM TRCKING))
L4 1-406-040-00 COIL (OSC) (AM OSC)
(AM FREQUENCY COVERAGE)
L5 1-409-944-11 COIL (DET) (FM DET)
L10 1-412-689-11 INDUCTOR 0.47uH
<TRANSISTOR>
Q101 8-729-036-90 TRANSISTOR KTC3198BL-AT
<RESISTOR>
R1 1-216-797-11 METAL CHIP 10 5% 1/16W
R2 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP,UK,CET)
R2 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(IT,C&SA,AR,HK,MX,SP,TW)
R3 1-216-815-11 METAL CHIP 330 5% 1/16W
R4 1-216-833-11 METAL CHIP 10K 5% 1/16W
R101 1-216-835-11 METAL CHIP 15K 5% 1/16W
R102 1-216-837-11 METAL CHIP 22K 5% 1/16W
R103 1-216-813-11 METAL CHIP 220 5% 1/16W
R104 1-216-813-11 METAL CHIP 220 5% 1/16W
R105 1-216-797-11 METAL CHIP 10 5% 1/16W
R106 1-216-821-11 METAL CHIP 1K 5% 1/16W
R107 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R108 1-216-821-11 METAL CHIP 1K 5% 1/16W
R109 1-216-837-11 METAL CHIP 22K 5% 1/16W
R110 1-216-835-11 METAL CHIP 15K 5% 1/16W
R111 1-216-821-11 METAL CHIP 1K 5% 1/16W
R112 1-216-853-11 METAL CHIP 470K 5% 1/16W
R113 1-249-407-11 CARBON 150 5% 1/4W F
R114 1-216-797-11 METAL CHIP 10 5% 1/16W
R115 1-216-819-11 METAL CHIP 680 5% 1/16W
(AEP,UK,IT,CET,AR,HK,SP)
R116 1-216-821-11 METAL CHIP 1K 5% 1/16W
(AEP,UK,IT,CET,AR,HK,SP)
R117 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(AEP,UK,IT,CET,AR,HK,SP)
R120 1-216-821-11 METAL CHIP 1K 5% 1/16W
R121 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R122 1-216-833-11 METAL CHIP 10K 5% 1/16W
R131 1-249-409-11 CARBON 220 5% 1/4W F
R132 1-249-409-11 CARBON 220 5% 1/4W F
<VARIABLE RESISTOR>
RV101 1-223-321-11 RES, VAR, CARBON 20K (VOLUME)
<SWITCH>
S101 1-572-625-11 SWITCH, SLIDE (FUNCTION)
S102 1-786-130-11 SWITCH, PUSH (1 KEY) (REC/PB)
<TRNSFORMER>
T1 1-433-741-11 TRANSFORMER, IF (AM IF)
******************************************************
MAIN
