Sony CFM-20

23
CFM-20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
POWER BOARD (C&SA,MX,TW)
***********
<CAPACITOR>
C901 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C902 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
<CONNECTOR>
* CNP901 1-785-654-11 PIN, CONNECTOR (PC BOARD) 2P
<DIODE>
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
<CABLE HOLDER>
* KH901 1-573-287-11 HOLDER, CABLE 2P
<TRANSFORMER>
0 T901 1-435-928-11 TRANSFORMER, POWER
*****************************************************
* 1-680-979-11 POWER BOARD (AEP,UK,IT,CET,AR,HK,SP)
***********
1-533-233-31 HOLDER, FUSE
<CAPACITOR>
C901 1-127-888-21 CERAMIC 0.1uF 10% 50V
C902 1-127-888-21 CERAMIC 0.1uF 10% 50V
<CONNECTOR>
* CNP901 1-785-654-11 PIN, CONNECTOR (PC BOARD) 2P
<DIODE>
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
<FUSE>
0 F901 1-532-500-31 FUSE (T630mAL 250V)
<JACK>
0 J901 1-526-838-11 INLET, AC 2P(AC IN)
<CABLE HOLDER>
* KH901 1-573-287-11 HOLDER, CABLE 2P
<TRANSFORMER>
0 T901 1-435-929-11 TRANSFORMER, POWER
*****************************************************
MISCELLANEOUS
*************
2 X-3380-915-1 CABINET (FRONT) SUB ASSY
(INCLUDING SP101)...(BLACK)(C&SA,MX,TW)
2 X-3380-916-1 CABINET (FRONT) SUB ASSY
(INCLUDING SP101)...(SILVER)(AEP,UK,CET)
2 X-3380-917-1 CABINET (FRONT) SUB ASSY
(INCLUDING SP101)...(BLACK)(AR,SP)
2 X-3380-918-1 CABINET (FRONT) SUB ASSY
(INCLUDING SP101)...(SILVER)(IT)
2 X-3380-919-1 CABINET (FRONT) SUB ASSY
(INCLUDING SP101)...(SILVER)(HK)
0 68 1-757-642-11 CORD, POWER (C&SA,MX,TW)
ANT1 1-754-160-11 ANTENNA, TELESCOPIC
ECM101 1-542-118-11 MICROPHONE, ELECTRET CONDENSER
HE101 1-500-680-11 HEAD, MAGNETIC (ERASE)
HRP101 1-500-679-11 HEAD,MAGNETIC(RECORD.PLAYBACK)
M101 A-3052-373-A MOTOR ASSY (REEL/CAPSTAN)
(INCLUDING PULLEY)
S501 1-762-679-11 SWITCH, LEAF (TAPE POWER)
*****************************************************
ACCESSORIES & PACKING MATERIALS
****************************
0 1-769-412-13 CORD, POWER (AEP,UK,IT,CET,HK,SP)
0 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK,HK)
0 1-783-952-11 CORD, POWER (AR)
3-228-217-11 MANUAL, INSTRUCTION (ENGLISH)
(C&SA,MX)
3-228-217-31 MANUAL, INSTRUCTION
(ENGLISH,SPANISH,FRENCH,GERMAN)
(AEP,UK,AR,HK,SP,TW)
3-228-217-41 MANUAL, INSTRUCTION
(DUTCH,PORTUGUESE,ITALIAN)(AEP,IT)
3-228-217-51 MANUAL, INSTRUCTION
(SWEDISH,FINNISH,RUSSIAN,SLOVAK)(CET)
3-228-217-61 MANUAL, INSTRUCTION
(POLISH,CZECH,HUGARIAN)(CET)
3-228-217-71 MANUAL, INSTRUCTION (SPANISH)(C&SA,MX)
3-228-217-81 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (HK,TW)
*****************************************************
*************
HARDWARE LIST
*************
#1 7-685-649-79 SCREW +BVTP 3X14 TYPE2 N-S
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-682-148-13 SCREW +P 3X8
#4 7-621-770-87 SCREW +P 2.6X5
#5 7-685-782-01 SCREW +PTT 2X5 (S)
Ver 1.1 2002.10
