Sony CFS-E2 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 23 —
R203 1-247-843-11 CARBON 3.3K 5% 1/4W
R204 1-249-434-11 CARBON 27K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R209 1-247-843-11 CARBON 3.3K 5% 1/4W
R210 1-249-389-11 CARBON 4.7 5% 1/4W F
R211 1-249-389-11 CARBON 4.7 5% 1/4W F
R217 1-249-417-11 CARBON 1K 5% 1/4W F
R301 1-249-409-11 CARBON 220 5% 1/4W F
R302 1-249-401-11 CARBON 47 5% 1/4W F
R303 1-247-895-00 CARBON 470K 5% 1/4W
R304 1-249-413-11 CARBON 470 5% 1/4W F
R305 1-249-421-11 CARBON 2.2K 5% 1/4W F
R306 1-249-421-11 CARBON 2.2K 5% 1/4W F
R307 1-249-398-11 CARBON 27 5% 1/4W F
R308 1-249-434-11 CARBON 27K 5% 1/4W
R309 1-249-440-11 CARBON 82K 5% 1/4W
R310 1-249-398-11 CARBON 27 5% 1/4W F
R311 1-249-417-11 CARBON 1K 5% 1/4W F
R312 1-247-807-31 CARBON 100 5% 1/4W
R313 1-249-411-11 CARBON 330 5% 1/4W
R314 1-249-411-11 CARBON 330 5% 1/4W
R316 1-249-417-11 CARBON 1K 5% 1/4W F
R317 1-249-417-11 CARBON 1K 5% 1/4W F
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-247-855-11 CARBON 10K 5% 1/4W
R602 1-247-903-00 CARBON 1M 5% 1/4W
R603 1-247-827-11 CARBON 680 5% 1/4W
R604 1-249-385-11 CARBON 2.2 5% 1/6W F
R605 1-249-385-11 CARBON 2.2 5% 1/6W F
R606 1-249-411-11 CARBON 330 5% 1/4W
R607 1-249-393-11 CARBON 10 5% 1/4W F
< VARIABLE RESISTOR >
RV1 1-223-641-11 RES, ADJ, CARBON 22K
RV301 1-238-869-11 RES, VAR, SLIDE 20/20 (VOLUME)
RV601 1-241-760-11 RES, ADJ, CARBON 470
< SWITCH >
S101 1-771-166-11 SWITCH, SLIDE (FUNCTION)
S102 1-554-123-00 SWITCH, SLIDE (MEGA BASS)
S301 1-762-234-11 SWITCH, SLIDE (ISS)
S302 1-692-167-11 SWITCH, SLIDE (REC)
< TRANSFORMER >
T1 1-406-040-00 COIL (OSC)
T2 1-416-155-11 COIL (455kHz IFT)
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
< THERMISTOR >
TH601 1-810-764-11 THERMISTOR, POSITIVE
TH602 1-809-279-11 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
***************
ANT1 1-501-832-11 ANTENNA, TELESCOPIC
HRP901 1-500-461-11 HEAD, MAGNETIC (REC/PB)
M901 X-3373-891-1 MOTOR ASSY (CAPSTAN/REEL)
MIC901 8-814-186-00 MICROPHONE,ELECTRET CONDENSER
S902 1-692-302-11 SWITCH, LEAF (MD POWER)
SP901 1-505-568-11 SPEAKER (5.7CM)
SP902 1-505-568-11 SPEAKER (5.7CM)
************************************************************
**************
HARDWARE LIST
**************
#1 7-627-553-68 SCREW,PRECISION +P 2 × 6
#2 7-627-852-08 SCREW,PRECISION +P 1.7 × 2.5
#3 7-685-104-19 SCREW +P 2 × 6 TYPE2 NON-SLIT
#4 7-685-134-19 SCREW +P 2.6 × 8 TYPE2 NON-SLIT
#5 7-685-647-14 SCREW +BVTP 3 × 10 TYPE2 N-S
#6 7-685-134-19 SCREW +P 2.6 × 8
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
! 1-475-237-11 ADAPTOR, AC (AEP)
! 1-475-238-11 ADAPTOR, AC (US, Canadian, Taiwan)
3-859-869-11 MANUAL, INSTRUCTION (ENGLISH)
(US, Canadian, Taiwan)
3-859-869-21 MANUAL, INSTRUCTION
(ENGLISH/GERMAN/FRENCH/SPANISH) (AEP)
3-859-869-31 MANUAL, INSTRUCTION
(DUTCH/SWEDISH/PORTUGUESE) (AEP)
3-859-869-41 MANUAL, INSTRUCTION (FRENCH)
(Canadian, Taiwan)
MAIN
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
Ver 1.2 2001. 04
