NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 21 —
SECTION 7
ELECTRICAL PARTS LIST
* 1-666-350-11 JACK BOARD
***********
< CAPACITOR >
C112 1-126-514-11 ELECT 22uF 20% 10V
C212 1-126-514-11 ELECT 22uF 20% 10V
< CONNECTOR >
* CN305 1-580-169-11 PIN, CONNECTOR (PC BOARD) 8P
< JACK >
J301 1-778-034-11 JACK (2)
J302 1-568-907-21 JACK,DC(POLARITY UNIFIED TYPE)
< RESISTOR >
R108 1-247-807-11 CARBON 100 5% 1/4W
R208 1-247-807-11 CARBON 100 5% 1/4W
************************************************************
* A-3293-606-A MAIN BOARD, COMPLETE
(US, Canadian, Taiwan)
*********************
* A-3293-607-A MAIN BOARD, COMPLETE (AEP)
*********************
3-011-921-01 GEAR (TUNING CAPACITOR)
3-011-922-01 HOLDER (FERRITE-ROD ANTENNA)
3-011-927-01 TERMINAL (+), BATTERY
7-627-852-08 SCREW,PRECISION +P 1.7 × 2.5
< ANTENNA >
ANT2 1-501-949-11 ANTENNA, FERRITE-ROD
< CAPACITOR >
C1 1-162-190-31 CERAMIC 1.8PF 20% 50V
C2 1-162-206-31 CERAMIC 20PF 5% 50V
(US, Canadian
, Taiwan
)
C2 1-162-207-31 CERAMIC 22PF 5% 50V
(AEP)
C3 1-102-953-00 CERAMIC 18PF 5% 50V
(US, Canadian
, Taiwan
)
C3 1-102-959-00 CERAMIC 22PF 5% 50V
(AEP)
C4 1-162-194-31 CERAMIC 3.9PF 10% 50V
(US, Canadian
, Taiwan
)
C4 1-162-196-31 CERAMIC 5.6PF 10% 50V
(AEP)
C5 1-124-907-11 ELECT 10uF 20% 50V
C6 1-162-306-11 CERAMIC 0.01uF 20% 16V
C7 1-162-306-11 CERAMIC 0.01uF 20% 16V
C8 1-162-294-31 CERAMIC 0.001uF 10% 50V
C9 1-162-306-11 CERAMIC 0.01uF 20% 16V
C10 1-162-193-31 CERAMIC 3.3PF 10% 50V
C11 1-126-963-11 ELECT 4.7uF 20% 50V
C12 1-124-903-11 ELECT 1uF 20% 50V
C13 1-104-664-11 ELECT 47uF 20% 16V
C14 1-104-664-11 ELECT 47uF 20% 16V
C15 1-162-306-11 CERAMIC 0.01uF 20% 16V
C16 1-162-841-11 CERAMIC 0.015uF 10% 16V
(AEP)
C16 1-162-842-11 CERAMIC 0.018uF 10% 16V
(US, Canadian
, Taiwan
)
C17 1-162-841-11 CERAMIC 0.015uF 10% 16V
(AEP)
C17 1-162-842-11 CERAMIC 0.018uF 10% 16V
(US, Canadian
, Taiwan
)
C18 1-115-871-11 ELECT 1uF 20% 50V
C19 1-126-959-11 ELECT 0.47uF 20% 50V
C20 1-126-963-11 ELECT 4.7uF 20% 50V
C21 1-124-257-00 ELECT 2.2uF 20% 50V
C22 1-124-443-00 ELECT 100uF 20% 10V
C24 1-162-306-11 CERAMIC 0.01uF 20% 16V
C25 1-126-959-11 ELECT 0.47uF 20% 50V
C26 1-126-959-11 ELECT 0.47uF 20% 50V
C27 1-162-282-31 CERAMIC 100PF 10% 50V
C28 1-126-514-11 ELECT 22uF 20% 10V
C101 1-162-294-31 CERAMIC 0.001uF 10% 50V
C102 1-126-786-11 ELECT 47uF 20% 16V
C103 1-162-843-11 CERAMIC 0.022uF 10% 16V
C104 1-162-294-31 CERAMIC 0.001uF 10% 50V
C105 1-162-282-31 CERAMIC 100PF 10% 50V
C106 1-162-294-31 CERAMIC 0.001uF 10% 50V
C107 1-162-306-11 CERAMIC 0.01uF 20% 16V
C109 1-162-832-11 CERAMIC 0.0027uF 10% 0
C110 1-126-959-11 ELECT 0.47uF 20% 50V
C111 1-162-282-31 CERAMIC 100PF 10% 50V
C113 1-161-057-00 CERAMIC 0.033uF 10% 50V
C114 1-136-167-00 FILM 0.15uF 5% 50V
C115 1-136-167-00 FILM 0.15uF 5% 50V
C115 1-162-219-31 CERAMIC 68PF 5% 50V
C201 1-162-294-31 CERAMIC 0.001uF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 16V
C203 1-162-843-11 CERAMIC 0.022uF 10% 16V
C204 1-162-294-31 CERAMIC 0.001uF 10% 50V
C205 1-162-282-31 CERAMIC 100PF 10% 50V
C207 1-162-306-11 CERAMIC 0.01uF 20% 16V
C209 1-162-832-11 CERAMIC 0.0027uF 10% 0
C210 1-124-465-00 ELECT 0.47uF 20% 50V
C211 1-162-282-31 CERAMIC 100PF 10% 50V
JACK MAIN
Ver 1.2 2001. 04
