— 4 —
SECTION 2
DISASSEMBL
Y
Note :
Follow the disassembly procedure in the numerical order given.
2-1.
REAR CABINET
2-2.
MAIN BO
ARD
1
Four scre
ws (
+ BVTP 3
×
24)
3
Connector (CN305)
4
Connector (CN1)
2
Unlock the cla
w
by pressing here
.
3
Connector (CN301)
4
Main boar
d
1
T
wo screws (+P 2.6
×
8)
2
Connector (CN304)
3
5
