REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-2
(a)
C302 1-110-591-91 ELECT 4.7MF 20% 50V
C303 1-163-085-00 CERAMIC CHIP 2PF 0.25PF 50V
C304 1-216-295-91 SHORT 0
C305 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C306 1-137-528-11 FILM 0.1MF 10% 250V
<CONNECTOR>
CN301*1-766-179-11 PIN, CONNECTOR (PC BOARD) 2P
CN302 1-695-915-11 TAB (CONTACT)
CN303 1-695-915-11 TAB (CONTACT)
CN304 1-695-915-11 TAB (CONTACT)
CN305*1-564-526-11 PLUG, CONNECTOR 11P
CN306*1-564-525-11 PLUG, CONNECTOR 10P
CN307*1-564-512-11 PLUG, CONNECTOR 9P
CN308 1-695-915-11 TAB (CONTACT)
CN309 1-564-524-11 PLUG, CONNECTOR 9P
CN310*1-564-507-11 PLUG, CONNECTOR 4P
CN312 1-785-221-11 PIN, CONNECTOR (PC BOARD) 13P
CN313 1-785-222-11 PIN, CONNECTOR (PC BOARD) 14P
CN314 1-564-517-11 PLUG, CONNECTOR 2P
CN315*1-564-508-11 PLUG, CONNECTOR 5P
CN316*1-564-518-11 PLUG, CONNECTOR 3P
<DIODE>
D001 8-719-109-89 ZENER DIODE RD5.6ESB2
D003 8-719-109-89 ZENER DIODE RD5.6ESB2
D005 8-719-911-19 DIODE 1SS119-25
D006 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 ZENER DIODE RD5.6ESB2
D008 8-719-109-89 ZENER DIODE RD5.6ESB2
D009 8-719-404-49 DIODE MA111
D013 8-719-404-49 DIODE MA111
D014 8-719-911-19 DIODE 1SS119-25
D015 8-719-105-99 ZENER DIODE RD6.2M-B1
D101 8-719-800-76 DIODE 1SS226
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D201 8-719-800-76 DIODE 1SS226
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D301 8-719-800-76 DIODE 1SS226
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
<FERRITE BEAD>
FB001 1-412-911-11 FERRITE 1.1UH
FB005 1-412-911-11 FERRITE 1.1UH
FB011 1-412-911-11 FERRITE 1.1UH
FB012 1-216-295-91 SHORT 0
FB013 1-216-295-91 SHORT 0
FB014 1-216-295-91 SHORT 0
FB015 1-216-295-91 SHORT 0
FB016 1-216-295-91 SHORT 0
FB101 1-216-295-91 SHORT 0
FB102 1-216-295-91 SHORT 0
FB110 1-412-911-11 FERRITE 1.1UH
FB201 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB210 1-412-911-11 FERRITE 1.1UH
FB301 1-216-295-91 SHORT 0
FB302 1-216-295-91 SHORT 0
FB310 1-412-911-11 FERRITE 1.1UH
<FILTER>
FL001 1-412-911-31 FERRITE 0UH
FL101 1-412-911-31 FERRITE 0UH
FL201 1-412-911-31 FERRITE 0UH
FL301 1-412-911-31 FERRITE 0UH
<TERMINAL>
GT101*1-537-738-21 TERMINAL, EARTH
GT102*1-537-738-21 TERMINAL, EARTH
GT103*1-537-738-21 TERMINAL, EARTH
GT104*1-537-738-21 TERMINAL, EARTH
<IC>
IC001 8-759-474-78 IC MM1382
IC002 8-759-399-84 IC LM2406T
IC003 8-759-541-26 IC LSC4514P2
IC004 8-759-434-40 IC TDA6103Q/N3,112
IC005 8-759-100-96 IC uPC4558G2
IC006 8-759-543-53 IC CXA8075S
IC008 8-759-542-46 IC M62392FP
IC009 8-759-925-72 IC SN74HC02ANS
<JACK>
J001 ¡ 1-251-637-11 SOCKET, PICTURE TUBE
<COIL>
L002 1-410-682-31 INDUCTOR 470UH
L003 1-412-529-11 INDUCTOR 22UH
L006 1-412-537-31 INDUCTOR 100UH
L101 1-410-498-11 INDUCTOR 1.2UH
L201 1-410-498-11 INDUCTOR 1.2UH
L301 1-410-498-11 INDUCTOR 1.2UH
<TRANSISTOR>
Q001 8-729-032-61 TRANSISTOR 2SC5022-02
Q004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q005 8-729-101-07 TRANSISTOR 2SB798-DL
