REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-3
(a)
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q007 8-729-140-47 TRANSISTOR 2SC3735-L-B35
Q008 8-729-422-27 TRANSISTOR 2SD601A-Q
Q009 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q010 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R002 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R003 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R004 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R005 1-216-113-00 RES,CHIP 470K 5% 1/10W
R006 1-216-025-91 RES,CHIP 100 5% 1/10W
R007 1-216-049-91 RES,CHIP 1K 5% 1/10W
R014 1-216-025-91 RES,CHIP 100 5% 1/10W
R016 1-216-073-00 RES,CHIP 10K 5% 1/10W
R017 1-216-025-91 RES,CHIP 100 5% 1/10W
R018 1-216-025-91 RES,CHIP 100 5% 1/10W
R020 1-216-025-91 RES,CHIP 100 5% 1/10W
R021 1-216-025-91 RES,CHIP 100 5% 1/10W
R022 1-216-295-91 SHORT 0
R023 1-216-295-91 SHORT 0
R026 1-216-073-00 RES,CHIP 10K 5% 1/10W
R027 1-216-073-00 RES,CHIP 10K 5% 1/10W
R028 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R029 1-216-095-00 RES,CHIP 82K 5% 1/10W
R030 1-216-295-91 SHORT 0
R031 1-216-049-91 RES,CHIP 1K 5% 1/10W
R032 1-216-665-11 METAL CHIP 3.9K 0.50%1/10W
R033 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R034 1-216-295-91 SHORT 0
R035 1-216-295-91 SHORT 0
R036 1-249-405-11 CARBON 100 5% 1/4W F
R037 1-216-295-91 SHORT 0
R040 1-216-113-00 RES,CHIP 470K 5% 1/10W
R041 1-163-085-00 CERAMIC CHIP 2PF 0.25PF 50V
R043 1-216-295-91 SHORT 0
R045 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R046 1-216-097-91 RES,CHIP 100K 5% 1/10W
R047 1-216-073-00 RES,CHIP 10K 5% 1/10W
R048 1-211-885-21 METAL 2.2M 5% 1W
R049 1-216-097-91 RES,CHIP 100K 5% 1/10W
R051 1-216-049-91 RES,CHIP 1K 5% 1/10W
R052 1-216-073-00 RES,CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R055 1-216-295-91 SHORT 0
R056 1-216-295-91 SHORT 0
R057 1-216-049-91 RES,CHIP 1K 5% 1/10W
R058 1-216-049-91 RES,CHIP 1K 5% 1/10W
R059 1-216-049-91 RES,CHIP 1K 5% 1/10W
R060 1-216-073-00 RES,CHIP 10K 5% 1/10W
R061 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R062 1-216-041-00 RES,CHIP 470 5% 1/10W
R063 1-216-295-91 SHORT 0
R064 1-202-830-00 SOLID 10K 20% 1/2W
R065 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R067 1-216-025-91 RES,CHIP 100 5% 1/10W
R068 1-216-073-00 RES,CHIP 10K 5% 1/10W
R069 1-216-077-00 RES,CHIP 15K 5% 1/10W
R070 1-216-077-00 RES,CHIP 15K 5% 1/10W
R071 1-216-073-00 RES,CHIP 10K 5% 1/10W
R072 1-216-105-91 RES,CHIP 220K 5% 1/10W
R073 1-216-105-91 RES,CHIP 220K 5% 1/10W
R074 1-216-083-00 RES,CHIP 27K 5% 1/10W
R075 1-216-073-00 RES,CHIP 10K 5% 1/10W
R101 1-215-394-00 METAL 75 1% 1/4W
R103 1-216-295-91 SHORT 0
R104 1-216-295-91 SHORT 0
R106 1-216-073-00 RES,CHIP 10K 5% 1/10W
R107 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R108 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R109 1-216-121-91 RES,CHIP 1M 5% 1/10W
R110 1-215-477-00 METAL 220K 1% 1/4W
R111 1-249-401-11 CARBON 47 5% 1/4W F
R112 1-216-013-00 RES,CHIP 33 5% 1/10W
R115 1-216-641-11 METAL CHIP 390 0.50%1/10W
R116 1-216-077-00 RES,CHIP 15K 5% 1/10W
R133 1-249-413-11 CARBON 470 5% 1/4W
R151 1-202-549-00 SOLID 100 20% 1/2W
R201 1-215-394-00 METAL 75 1% 1/4W
R203 1-216-295-91 SHORT 0
R204 1-216-295-91 SHORT 0
R206 1-216-073-00 RES,CHIP 10K 5% 1/10W
R207 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R208 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R209 1-216-121-91 RES,CHIP 1M 5% 1/10W
R210 1-215-477-00 METAL 220K 1% 1/4W
R211 1-249-401-11 CARBON 47 5% 1/4W F
R212 1-216-013-00 RES,CHIP 33 5% 1/10W
R215 1-216-641-11 METAL CHIP 390 0.50%1/10W
R216 1-216-077-00 RES,CHIP 15K 5% 1/10W
R233 1-247-791-91 CARBON 22 5% 1/4W
R251 1-202-549-00 SOLID 100 20% 1/2W
R301 1-215-394-00 METAL 75 1% 1/4W
R303 1-216-295-91 SHORT 0
R304 1-216-295-91 SHORT 0
R306 1-216-073-00 RES,CHIP 10K 5% 1/10W
R307 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R308 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R309 1-216-121-91 RES,CHIP 1M 5% 1/10W
R310 1-215-477-00 METAL 220K 1% 1/4W
R311 1-249-401-11 CARBON 47 5% 1/4W F
R312 1-216-013-00 RES,CHIP 33 5% 1/10W
R313 1-216-025-91 RES,CHIP 100 5% 1/10W
R314 1-249-417-11 CARBON 1K 5% 1/4W F
R315 1-216-641-11 METAL CHIP 390 0.50%1/10W
R316 1-216-077-00 RES,CHIP 15K 5% 1/10W
R333 1-247-791-91 CARBON 22 5% 1/4W
R351 1-202-549-00 SOLID 100 20% 1/2W
To Next Page
