REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡
sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-4
(a)(aa)
<SPARK GAP>
SG001 1-519-422-11 GAP, SPARK
SG002 1-519-422-11 GAP, SPARK
SG101 1-517-499-21 GAP, SPARK
SG201 1-517-499-21 GAP, SPARK
SG301 1-517-499-21 GAP, SPARK
*******************************************************************************
* 8-933-326-00 AA BOARD, COMPLETE
******************************
<CAPACITOR>
C800 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C802 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C804 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C805 1-126-786-11 ELECT 47MF 20% 16V
C808 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C809 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C810 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C814 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C820 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C821 1-164-489-11 CERAMIC CHIP 0.22MF 10% 16V
C822 1-126-795-11 ELECT 10MF 20% 25V
C823 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C824 1-126-795-11 ELECT 10MF 20% 25V
C825 1-126-795-11 ELECT 10MF 20% 25V
C827 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C828 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C829 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C830 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C832 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C833 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C834 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C835 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
<CONNECTOR>
CN800 1-569-515-11 PIN, CONNECTOR 14P
CN801 1-785-254-11 PIN, CONNECTOR (PC BOARD) 13P
<DIODE>
D800 8-719-404-49 DIODE MA111
D801 8-719-404-49 DIODE MA111
D802 8-719-404-49 DIODE MA111
D803 8-719-158-18 ZENER DIODE RD5.6SB3
D804 8-719-404-49 DIODE MA111
D805 8-719-404-49 DIODE MA111
<IC>
IC804 8-759-541-28 IC CXD8770Q
IC805 8-759-058-50 IC XRA10324AF
IC807 8-759-011-65 IC MC74HC4053F
<TRANSISTOR>
Q801 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q803 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q805 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q806 8-729-216-22 TRANSISTOR 2SA1162-G
Q807 8-729-216-22 TRANSISTOR 2SA1162-G
Q808 8-729-216-22 TRANSISTOR 2SA1162-G
Q809 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q810 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R800 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R802 1-216-013-00 RES,CHIP 33 5% 1/10W
R803 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R804 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R805 1-216-013-00 RES,CHIP 33 5% 1/10W
R806 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R807 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R808 1-216-049-91 RES,CHIP 1K 5% 1/10W
R809 1-216-013-00 RES,CHIP 33 5% 1/10W
R810 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R811 1-216-121-91 RES,CHIP 1M 5% 1/10W
R813 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R814 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R815 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R816 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R817 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R818 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R819 1-216-121-91 RES,CHIP 1M 5% 1/10W
R820 1-216-049-91 RES,CHIP 1K 5% 1/10W
R821 1-216-637-11 METAL CHIP 270 0.50%1/10W
R822 1-216-665-11 METAL CHIP 3.9K 0.50%1/10W
R823 1-216-089-91 RES,CHIP 47K 5% 1/10W
R824 1-216-097-91 RES,CHIP 100K 5% 1/10W
R825 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R826 1-216-041-00 RES,CHIP 470 5% 1/10W
R827 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R828 1-216-041-00 RES,CHIP 470 5% 1/10W
R832 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R833 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R834 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R835 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R836 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R840 1-216-295-91 SHORT 0
R841 1-216-295-91 SHORT 0
R842 1-216-295-91 SHORT 0
R843 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R844 1-216-067-00 RES,CHIP 5.6K 5% 1/10W
R846 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R847 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R848 1-216-647-11 METAL CHIP 680 0.50%1/10W
