Sony CPD-101VS - Page 45

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-11
(d)(da)
<RELAY>
RY601 1-755-031-11 RELAY
<SWITCH>
S601 ¡ 1-571-433-31 SWITCH, PUSH (AC POWER)
S901 1-692-431-21 SWITCH, TACTILE (CONT+)
S903 1-692-431-21 SWITCH, TACTILE (VOLUME+)
S904 1-692-431-21 SWITCH, TACTILE (VOLUME-)
S905 1-692-431-21 SWITCH, TACTILE (GPE)
S906 1-692-431-21 SWITCH, TACTILE (RESET)
S907 1-692-431-21 SWITCH, TACTILE (MUTE)
S910 1-692-431-21 SWITCH, TACTILE (CONT-)
S911 1-692-431-21 SWITCH, TACTILE (MENU)
<SPARK GAP>
SG501 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 ¡ X-4035-935-1 TRANSFORMER ASSY, FLYBACK
(NX-4431//J1K4)
T503 1-429-109-11 TRANSFORMER, FERRITE (DFT)
T504 1-429-103-11 TRANSFORMER, FERRITE (HDT)
T505 1-426-998-11 TRANSFORMER, FERRITE (HST)
T601 1-416-286-21 COIL, CHOKE 515UH
T602 ¡ 1-431-386-11 TRANSFORMER, CONVERTER (PIT)
T603 1-429-992-11 TRANSFORMER, CONVERTER (PRT)
<THERMISTOR>
TH401 1-803-114-11THERMISTOR, POSITIVE
TH501 1-807-796-11THERMISTOR
TH601¡1-810-990-11THERMISTOR
TH602 1-809-827-11THERMISTOR, POSITIVE
<VARISTOR>
VA602¡1-801-268-51VARISTOR TNR14V471K660
<CRYSTAL>
X901 1-767-641-11 VIBRATOR, CRYSTAL
X902 1-767-933-11 OSCILLATOR, CERAMIC
********************************************************************************
* 8-933-240-00 DA BOARD, COMPLETE
******************************
<CAPACITOR>
C1608 1-163-275-11 CERAMIC CHIP 0.001MF 5% 50V
C1609 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1610 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C1611 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C1612 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C1615 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1616 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C1618 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C1626 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
<CONNECTOR>
CN1600*1-774-512-11CONNECTOR, BPARD TO BOARD 10P
<DIODE>
D1604 8-719-977-81 ZENER DIODE DTZ33B
D1605 8-719-056-95 ZENER DIODE UDZ-TE-17-22B
D1610 8-719-404-49 DIODE MA111
<IC>
IC1601 8-759-462-65 IC TK75003D
IC1603 8-759-198-31 IC uPC1093J-1-T
<CHIP CONDUCTOR>
JR1601 1-216-295-91 SHORT 0
JR1602 1-216-295-91 SHORT 0
<TRANSISTOR>
Q1603 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1604 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q1605 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1606 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R1603 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R1607 1-216-105-91 RES,CHIP 220K 5% 1/10W
R1608 1-216-017-91 RES,CHIP 47 5% 1/10W
R1609 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1611 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1614 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1615 1-216-089-91 RES,CHIP 47K 5% 1/10W
R1620 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1621 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R1622 1-216-073-00 RES,CHIP 10K 5% 1/10W
R1623 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1624 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R1641 1-216-073-00 RES,CHIP 10K 5% 1/10W
********************************************************************************
