REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-12
(u)
* 8-933-329-00 U BOARD, COMPLETE
****************************
4-382-854-11 SCREW (M3X10), P, SW (+) (IC5201)
<CAPACITOR>
C5021 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5202 1-126-964-11 ELECT 10MF 20% 50V
C5203 1-126-964-11 ELECT 10MF 20% 50V
C5205 1-107-698-11 ELECT 10MF 20% 25V
C5206 1-107-698-11 ELECT 10MF 20% 25V
C5207 1-164-695-11 CERAMIC CHIP 0.0022MF 5% 50V
C5208 1-164-695-11 CERAMIC CHIP 0.0022MF 5% 50V
C5209 1-164-344-11 CERAMIC CHIP 0.068MF 10% 25V
C5210 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C5211 1-163-809-11 CERAMIC CHIP 0.047MF 10% 25V
C5212 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5213 1-126-965-11 ELECT 22MF 20% 50V
C5214 1-104-664-11 ELECT 47MF 20% 25V
C5215 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C5217 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C5218 1-104-663-11 ELECT 33MF 20% 25V
C5219 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5220 1-164-344-11 CERAMIC CHIP 0.068MF 10% 25V
C5221 1-126-941-11 ELECT 470MF 20% 25V
C5223 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C5230 1-104-664-11 ELECT 47MF 20% 10V
C5236 1-104-664-11 ELECT 47MF 20% 16V
C5240 1-126-965-11 ELECT 22MF 20% 50V
C5257 1-126-960-11 ELECT 1MF 20% 50V
C5258 1-104-664-11 ELECT 47MF 20% 16V
C5260 1-125-959-11 ELECT 4700MF 25V
C5263 1-125-959-11 ELECT 4700MF 25V
C5264 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5266 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5275 1-136-165-00 FILM 0.1MF 5% 50V
C5276 1-136-165-00 FILM 0.1MF 5% 50V
C5279 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5280 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5281 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5282 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C5283 1-126-963-11 ELECT 4.7MF 20% 50V
C5284 1-126-963-11 ELECT 4.7MF 20% 50V
C5285 1-126-964-11 ELECT 10MF 20% 50V
C5296 1-163-038-91 CERAMIC CHIP 0.1MF 25V
C5297 1-104-664-11 ELECT 47MF 20% 25V
C5298 1-126-964-11 ELECT 10MF 20% 50V
C5303 1-126-963-11 ELECT 4.7MF 20% 50V
C5304 1-126-963-11 ELECT 4.7MF 20% 50V
C5310 1-163-989-11 CERAMIC CHIP 0.033MF 10% 25V
C5402 1-126-964-11 ELECT 10MF 20% 50V
C5403 1-126-960-11 ELECT 1MF 20% 50V
C5405 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
C5616 1-126-964-11 ELECT 10MF 20% 50V
C5620 1-125-960-11 ELECT 4700MF 25V
<CONNECTOR>
CN5200*1-564-506-11PLUG, CONNECTOR 3P
CN5202*1-564-508-11PLUG, CONNECTOR 5P
CN5204*1-564-509-11PLUG, CONNECTOR 6P
CN5601*1-564-508-11PLUG, CONNECTOR 5P
CN5605 1-695-915-11TAB (CONTACT)
CN5606 1-695-915-11TAB (CONTACT)
CN5607 1-695-915-11TAB (CONTACT)
<DIODE>
D5200 8-719-404-49 DIODE MA111
D5201 8-719-404-49 DIODE MA111
D5202 8-719-404-49 DIODE MA111
D5203 8-719-404-49 DIODE MA111
D5204 8-719-404-49 DIODE MA111
D5205 8-719-510-46 DIODE D1NL20
D5206 8-719-404-49 DIODE MA111
D5211 8-719-404-49 DIODE MA111
D5212 8-719-404-49 DIODE MA111
D5401 8-719-977-28 ZENER DIODE DTZ10B
D5402 8-719-404-49 DIODE MA111
D5403 8-719-404-49 DIODE MA111
D5404 8-719-404-49 DIODE MA111
D5601 8-719-404-49 DIODE MA111
D5602 8-719-404-49 DIODE MA111
D5608 8-719-404-49 DIODE MA111
<IC>
IC5200 8-759-273-12 IC TDA7315D013TR
IC5201 8-759-980-43 IC TDA2009A
IC5202 8-759-100-96 IC uPC4558G2
IC5204 8-759-100-96 IC uPC4558G2
IC5601 8-759-168-19 IC TA78L09F-TE12L
<JACK>
J5401 1-563-330-11 JACK
<COIL>
L5201 1-410-435-21 INDUCTOR 220UH
L5202 1-410-435-21 INDUCTOR 220UH
<IC LINK>
PS5200¡1-532-984-91LINK, IC (2A/90V AC, 60V DC)
<TRANSISTOR>
Q5001 8-729-422-27 TRANSISTOR 2SD601A-Q
Q5201 8-729-216-22 TRANSISTOR 2SA1162-G
Q5202 8-729-216-22 TRANSISTOR 2SA1162-G
Q5205 8-729-216-22 TRANSISTOR 2SA1162-G
