REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by shading
and mark
¡ are critical for safety.
Replace only with part number specified.
Les composants identifiés per un tramé
et une marque
¡ sont critiques pour la
sécurité. Ne les remplacer que par une
piéce portant le numéro spécifié.
CPD-101VS
7-13
(u)(j)
Q5206 8-729-322-37 TRANSISTOR 2SJ175
Q5207 8-729-422-27 TRANSISTOR 2SD601A-Q
Q5215 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q5216 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q5401 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q5402 8-729-920-21 TRANSISTOR DTC314TK-T-146
<RESISTOR>
R5201 1-216-001-00 RES,CHIP 10 5% 1/10W
R5202 1-240-095-21 RES,CHIP 100K 5% 1/10W
R5203 1-240-095-21 RES,CHIP 100K 5% 1/10W
R5204 1-240-095-21 RES,CHIP 100K 5% 1/10W
R5205 1-240-095-21 RES,CHIP 100K 5% 1/10W
R5206 1-240-099-21 RES,CHIP 220K 5% 1/10W
R5207 1-240-103-21 RES,CHIP 470K 5% 1/10W
R5208 1-240-099-21 RES,CHIP 220K 5% 1/10W
R5209 1-240-103-21 RES,CHIP 470K 5% 1/10W
R5210 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5211 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5213 1-216-295-91 SHORT 0
R5214 1-249-377-11 CARBON 0.47 5% 1/4W F
R5216 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5217 1-216-025-91 RES,CHIP 100 5% 1/10W
R5218 1-216-017-91 RES,CHIP 47 5% 1/10W
R5219 1-240-082-21 RES,CHIP 8.2K 5% 1/10W
R5222 1-216-025-91 RES,CHIP 100 5% 1/10W
R5223 1-240-082-21 RES,CHIP 8.2K 5% 1/10W
R5225 1-216-081-00 RES,CHIP 22K 5% 1/10W
R5229 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5230 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5232 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5233 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5239 1-216-295-91 SHORT 0
R5241 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5246 1-249-389-11 CARBON 4.7 5% 1/4W F
R5252 1-249-389-11 CARBON 4.7 5% 1/4W F
R5258 1-216-295-91 SHORT 0
R5269 1-216-089-91 RES,CHIP 47K 5% 1/10W
R5270 1-216-093-00 RES,CHIP 68K 5% 1/10W
R5271 1-216-089-91 RES,CHIP 47K 5% 1/10W
R5272 1-216-089-91 RES,CHIP 47K 5% 1/10W
R5276 1-240-075-21 RES,CHIP 2.2K 5% 1/10W
R5277 1-240-075-21 RES,CHIP 2.2K 5% 1/10W
R5281 1-240-091-21 RES,CHIP 47K 5% 1/10W
R5282 1-240-091-21 RES,CHIP 47K 5% 1/10W
R5283 1-216-683-11 RES,CHIP 22K 5% 1/10W
R5284 1-216-683-11 RES,CHIP 22K 5% 1/10W
R5298 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R5299 1-216-675-11 METAL CHIP 10K 0.50%1/10W
R5300 1-240-082-21 RES,CHIP 8.2K 5% 1/10W
R5301 1-240-082-21 RES,CHIP 8.2K 5% 1/10W
R5303 1-216-295-91 SHORT 0
R5304 1-216-295-91 SHORT 0
R5306 1-240-075-21 RES,CHIP 2.2K 5% 1/10W
R5307 1-240-075-21 RES,CHIP 2.2K 5% 1/10W
R5309 1-240-052-21 RES,CHIP 27 5% 1/10W
R5310 1-216-651-11 RES,CHIP 1K 5% 1/10W
R5311 1-240-052-21 RES,CHIP 27 5% 1/10W
R5325 1-216-675-11 RES,CHIP 10K 5% 1/10W
R5326 1-216-675-11 RES,CHIP 10K 5% 1/10W
R5328 1-216-081-00 RES,CHIP 22K 5% 1/10W
R5401 1-216-081-00 RES,CHIP 22K 5% 1/10W
R5402 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5403 1-216-081-00 RES,CHIP 22K 5% 1/10W
R5404 1-216-049-91 RES,CHIP 1K 5% 1/10W
R5406 1-216-089-91 RES,CHIP 47K 5% 1/10W
R5407 1-216-295-91 SHORT 0
R5408 1-216-295-91 SHORT 0
********************************************************************************
* 1-669-820-11 J BOARD
************
<CAPACITOR>
C6001 1-115-339-11 CERAMIC CHIP 0.1MF 10% 50V
<CONNECTOR>
CN6001 1-695-915-11TAB (CONTACT)
CN6002*1-564-508-11PLUG, CONNECTOR 5P
CN6003*1-564-507-11PLUG, CONNECTOR 4P
<DIODE>
D6000 8-719-404-49 DIODE MA111
D6001 8-719-404-49 DIODE MA111
<JACK>
J6002 1-568-267-11 JACK
<TRANSISTOR>
Q6001 8-729-920-21 TRANSISTOR DTC314TK-T-146
Q6002 8-729-920-21 TRANSISTOR DTC314TK-T-146
<RESISTOR>
R6000 1-215-863-11 METAL OXIDE 100 5% 1W F
R6001 1-215-863-11 METAL OXIDE 100 5% 1W F
R6002 1-249-397-11 CARBON 22 5% 1/4W F
R6003 1-249-397-11 CARBON 22 5% 1/4W F
