— 38 —
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
CPD-E200
A
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
DIODE
D001 8-719-970-02 DIODE 1SR139-400T31
D002 8-719-911-19 DIODE 1SS119-25
D003 8-719-911-19 DIODE 1SS119-25
D004 8-719-911-19 DIODE 1SS119-25
D005 8-719-911-19 DIODE 1SS119-25
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D014 8-719-911-19 DIODE 1SS119-25
D015 8-719-911-19 DIODE 1SS119-25
D104 8-719-970-83 DIODE HSS82
D105 8-719-970-83 DIODE HSS82
D106 8-719-970-83 DIODE HSS82
D111 8-719-062-51 DIODE 1PS226-115
D204 8-719-970-83 DIODE HSS82
D205 8-719-970-83 DIODE HSS82
D206 8-719-970-83 DIODE HSS82
D211 8-719-062-51 DIODE 1PS226-115
D304 8-719-970-83 DIODE HSS82
D305 8-719-970-83 DIODE HSS82
D306 8-719-970-83 DIODE HSS82
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB001 1-412-911-11 FERRITE 0UH
FB002 1-412-911-11 FERRITE 0UH
FB004 1-412-911-11 FERRITE 0UH
FB005 1-412-911-11 FERRITE 0UH
FB006 1-412-911-11 FERRITE 0UH
FB009 1-412-911-11 FERRITE 0UH
FB010 1-412-911-11 FERRITE 0UH
FB011 1-412-911-11 FERRITE 0UH
FB012 1-412-911-11 FERRITE 0UH
FB014 1-412-911-11 FERRITE 0UH
FB015 1-412-911-11 FERRITE 0UH
FB016 1-412-911-11 FERRITE 0UH
FB017 1-412-911-11 FERRITE 0UH
FB018 1-412-911-11 FERRITE 0UH
FB019 1-412-911-11 FERRITE 0UH
FB102 1-216-295-91 SHORT
FB202 1-216-295-91 SHORT
FB302 1-216-295-91 SHORT
FILTER
FL002 1-412-911-11 FERRITE 0UH
IC
IC001 8-752-090-63 IC CXA2067S
IC002 8-759-593-11 IC LM2415
IC003 8-759-589-35 IC CXD9516P
IC004 8-749-016-27 IC H8D2957
IC005 8-759-100-96 IC UPC4558G2
IC006 8-759-269-07 IC SN74HCT02ANSR
JACK
J001
!
1-251-598-11 SOCKET, CRT
CHIP CONDUCTOR
JR002 1-216-296-91 SHORT
JR005 1-216-296-91 SHORT
JR006 1-216-296-91 SHORT
JR007 1-216-296-91 SHORT
JR016 1-216-296-91 SHORT
JR017 1-216-296-91 SHORT
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
COIL
L002 1-410-682-31 INDUCTOR 470UH
L003 1-408-397-00 INDUCTOR 1UH
L005 1-412-529-11 INDUCTOR 22UH
L007 1-410-482-31 INDUCTOR 100UH
L009 1-216-295-91 SHORT
L010 1-412-911-11 FERRITE 0UH
L101 1-410-750-41 INDUCTOR 0.47UH
L102 1-412-052-21 INDUCTOR CHIP 1UH
L201 1-410-750-41 INDUCTOR 0.47UH
L301 1-410-750-41 INDUCTOR 0.47UH
TRANSISTOR
Q001 8-729-046-80 TRANSISTOR 2SC4634LS-CB11
Q006 8-729-120-28 TRANSISTOR 2SC1623-L5L6
RESISTOR
R002 1-216-043-91 RES, CHIP 560 5% 1/10W
R003 1-216-067-00 RES, CHIP 5.6K 5% 1/10W
R004 1-216-055-00 RES, CHIP 1.8K 5% 1/10W
R005 1-216-121-91 RES, CHIP 1M 5% 1/10W
R006 1-216-025-91 RES, CHIP 100 5% 1/10W
