— 39 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
CPD-E200
Les composants identifies per un trame
et une marque
¡¡
¡¡
¡ sont critiques pour la
securite. Ne les remplacer que par une
Note:
The components identified by shading
and mark
¡¡
¡¡
¡
are critical for safety.
Replace only with part number specified.
Note:
D
R007 1-216-025-91 RES, CHIP 100 5% 1/10W
R009 1-216-073-00 RES, CHIP 10K 5% 1/10W
R011 1-216-073-00 RES, CHIP 10K 5% 1/10W
R012 1-216-073-00 RES, CHIP 10K 5% 1/10W
R013 1-216-025-91 RES, CHIP 100 5% 1/10W
R014 1-216-025-91 RES, CHIP 100 5% 1/10W
R017 1-216-025-91 RES, CHIP 100 5% 1/10W
R018 1-216-025-91 RES, CHIP 100 5% 1/10W
R020 1-216-025-91 RES, CHIP 100 5% 1/10W
R021 1-216-025-91 RES, CHIP 100 5% 1/10W
R022 1-216-033-00 RES, CHIP 220 5% 1/10W
R023 1-216-049-91 RES, CHIP 1K 5% 1/10W
R024 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R028 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R029 1-216-099-00 RES, CHIP 120K 5% 1/10W
R030 1-216-025-91 RES, CHIP 100 5% 1/10W
R031 1-216-049-91 RES, CHIP 1K 5% 1/10W
R035 1-216-295-91 SHORT
R041 1-216-025-91 RES, CHIP 100 5% 1/10W
R045 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R046 1-216-097-91 RES,CHIP 100K 5% 1/10W
R047 1-216-073-00 RES, CHIP 10K 5% 1/10W
R048 1-211-885-21 METAL 2.2M 5% 1W
R049 1-216-697-91 METAL CHIP 82K 0.50% 1/10W
R051 1-216-049-91 RES, CHIP 1K 5% 1/10W
R052 1-216-073-00 RES, CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R062 1-216-295-91 SHORT
R064 1-202-830-00 SOLID 10K 20% 1/2W
R102 1-216-113-00 RES, CHIP 470K 5% 1/10W
R104 1-216-017-91 RES, CHIP 47 5% 1/10W
R106 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R107 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R108 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R109 1-216-113-00 RES, CHIP 470K 5% 1/10W
R111 1-249-401-11 CARBON 47 5% 1/4W F
R117 1-216-295-91 SHORT
R118 1-216-019-00 RES,CHIP 56 5% 1/10W
R119 1-216-113-00 RES, CHIP 470K 5% 1/10W
R130 1-216-295-91 SHORT
R133 1-249-413-11 CARBON 470 5% 1/4W
R151 1-202-549-00 SOLID 100 20% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R202 1-216-113-00 RES, CHIP 470K 5% 1/10W
R204 1-216-017-91 RES, CHIP 47 5% 1/10W
R206 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R207 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R208 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R209 1-216-113-00 RES, CHIP 470K 5% 1/10W
R211 1-249-401-11 CARBON 47 5% 1/4W F
R217 1-216-295-91 SHORT
R218 1-216-019-00 RES, CHIP 56 5% 1/10W
R219 1-216-113-00 RES, CHIP 470K 5% 1/10W
R230 1-216-295-91 SHORT
R233 1-249-413-11 CARBON 470 5% 1/4W
R251 1-202-549-00 SOLID 100 20% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R302 1-216-113-00 RES, CHIP 470K 5% 1/10W
R304 1-216-017-91 RES, CHIP 47 5% 1/10W
R306 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R307 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R308 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R309 1-216-113-00 RES, CHIP 470K 5% 1/10W
R311 1-249-401-11 CARBON 47 5% 1/4W F
R317 1-216-295-91 SHORT
R318 1-216-019-00 RES, CHIP 56 5% 1/10W
R319 1-216-113-00 RES, CHIP 470K 5% 1/10W
R330 1-216-295-91 SHORT
R333 1-249-413-11 CARBON 470 5% 1/4W
R351 1-202-549-00 SOLID 100 20% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
SPARK GAP
SG001
!
1-519-422-11 GAP, SPARK
SG002
!
1-517-499-21 GAP, SPARK
SG101
!
1-517-499-21 GAP, SPARK
SG201
!
1 -517-499-21 GAP, SPARK
SG301
!
1-517-499-21 GAP, SPARK
* A-1346-853-A D BOARD, COMPLETE
1-533-223-11 CLIP, FUSE
3-703-319-01 PURSE LOCK (DIA.15)
3-710-578-01 COVER, VOLUME, 6 MOLD
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
CAPACITOR
C401 1-128-528-11 ELECT 470MF 20% 25V
C402 1-106-228-00 MYLAR 0.22MF 10% 100V
C403 1-107-911-11 ELECT 220MF 20% 50V
C404 1-128-528-11 ELECT 470MF 20% 25V
C405 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C406 1-137-368-11 FILM 0.0047MF 5% 50V
C407 1-137-372-11 FILM 0.022MF 5% 50V
C501 1-126-964-11 ELECT 10MF 20% 50V
C502 1-137-370-11 FILM 0.01MF 5% 50V
D
A
