— 43 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
CPD-E200
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
IC608 8-759-231-53 IC TA7805S
IC701 8-759-595-52 IC CXA8070AP
IC702 8-749-015-00 IC STK391-110
IC703 8-759-822-38 IC LA6510
IC901
!
8-759-596-69 IC CXD9528S
IC902 8-759-594-40 IC CXA8071CP
IC904 8-759-352-91 IC PST9143NL
IC905 8-759-527-76 IC M24C08-MN6T
CHIP CONDUCTOR
JR001 1-216-296-91 SHORT
JR003 1-216-295-91 SHORT
JR004 1-216-295-91 SHORT
JR006 1-216-295-91 SHORT
JR007 1-216-295-91 SHORT
JR008 1-216-296-91 SHORT
JR009 1-216-295-91 SHORT
JR010 1-216-296-91 SHORT
JR011 1-216-296-91 SHORT
JR012 1-216-295-91 SHORT
JR013 1-216-295-91 SHORT
JR014 1-216-296-91 SHORT
JR015 1-216-295-91 SHORT
JR016 1-216-295-91 SHORT
JR017 1-216-295-91 SHORT
JR018 1-216-295-91 SHORT
JR019 1-216-296-91 SHORT
JR020 1-216-296-91 SHORT
JR021 1-216-296-91 SHORT
JR022 1-216-295-91 SHORT
JR023 1-216-295-91 SHORT
JR024 1-216-296-91 SHORT
JR025 1-216-296-91 SHORT
JR027 1-216-296-91 SHORT
JR028 1-216-296-91 SHORT
JR029 1-216-295-91 SHORT
JR030 1-216-295-91 SHORT
JR032 1-216-296-91 SHORT
JR033 1-216-296-91 SHORT
JR034 1-216-295-91 SHORT
JR038 1-216-296-91 SHORT
JR602 1-216-295-91 SHORT
JR604 1-216-295-91 SHORT
JR606 1-216-295-91 SHORT
COIL
L501 1-406-663-21 INDUCTOR 47UH
L502 1-406-663-21 INDUCTOR 47UH
L503 1-411-594-41 INDUCTOR 5MMH
L505 1-412-552-11 INDUCTOR 2.2MMH
L506 1-412-548-31 INDUCTOR 820UH
L507 1-414-856-11 INDUCTOR 10UH
L508 1-419-198-21 COIL, HORIZONTAL LINEARITY
L509 1-419-198-21 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L511 1-414-187-11 INDUCTOR 47UH
L513 1-414-856-11 INDUCTOR 10UH
L602 1-412-529-11 INDUCTOR 22UH
L603 1-412-537-31 INDUCTOR 100UH
L604 1-406-665-11 INDUCTOR 100UH
L606 1-406-665-11 INDUCTOR 100UH
FILTER
LF602
!
1-429-180-11 TRANSFORMER, LINE FILTER
TRANSISTOR
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q503 8-729-035-54 TRANSISTOR 2SJ449
Q504 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q505 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q506 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q507 8-729-049-17 TRANSISTOR 2SC5302-SONY-CC
Q508 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q510 8-729-046-60 TRANSISTOR 2SK2605LBSONY
Q511 8-729-042-34 TRANSISTOR IRFU110A
Q512 8-729-047-72 TRANSISTOR 2SK3155-01
Q513 8-729-043-41 TRANSISTOR 2SK2098-01MR-F 119
Q514 8-729-047-72 TRANSISTOR 2SK3155-01
Q515 8-729-047-72 TRANSISTOR 2SK3155-01
Q516 8-729-047-72 TRANSISTOR 2SK3155-01
Q518 8-729-140-50 TRANSISTOR 2SC3209LK
Q519 8-729-029-68 TRANSISTOR DTC114TSA
Q520 8-729-035-54 TRANSISTOR 2SJ449
Q521 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q522 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q524 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q525 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q601 8-729-029-92 TRANSISTOR DTC143ESA
Q602
!
8-729-048-61 TRANSISTOR 2SK2843LBS2SONY
Q603 8-729-900-53 TRANSISTOR DTC114EK
Q604 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q605 8-729-900-53 TRANSISTOR DTC114EK
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
