Sony CPD-E200 - Chassis Exploded View and Parts

— 44 —
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
CPD-E200
D
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
RESISTOR
R401 1-249-383-11 CARBON 1.5 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-661-21 METAL 1.5 1% 1/4W
R404 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R405 1-214-661-21 METAL 1.5 1% 1/4W
R406 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R407 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R408 1-216-073-00 RES, CHIP 10K 5% 1/10W
R409 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R410 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R500 1-249-377-11 CARBON 0.47 5% 1/4W F
R501 1-216-025-91 RES, CHIP 100 5% 1/10W
R502 1-218-758-11 METAL CHIP 180K 0.50% 1/10W
R503 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R504 1-249-377-11 CARBON 0.47 5% 1/4W F
R505 1-216-073-00 RES, CHIP 10K 5% 1/10W
R506 1-215-481-00 METAL 330K 1% 1/4W
R507 1-215-431-00 METAL 2.7K 1% 1/4W
R508 1-247-807-31 CARBON 100 5% 1/4W
R509 1-247-863-91 CARBON 22K 5% 1/4W
R510
!
1-215-437-00 METAL 4.7K 1% 1/4W
R511 1-249-381-11 CARBON 1 5% 1/4W F
R512 1-249-389-11 CARBON 4.7 5% 1/4W
R513 1-215-888-00 METAL OXIDE 220 5% 2W F
R514 1-216-081-00 RES, CHIP 22K 5% 1/10W
R515 1-249-417-11 CARBON 1K 5% 1/4W F
R516 1-214-844-81 METAL 150 1% 1/2W
R517 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R518 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R519 1-215-463-00 METAL 56K 1% 1/4W
R520 1-249-397-11 CARBON 22 5% 1/4W F
R521 1-249-417-11 CARBON 1K 5% 1/4W F
R522 1-249-401-11 CARBON 47 5% 1/4W
R523 1-215-463-00 METAL 56K 1% 1/4W
R524 1-215-463-00 METAL 56K 1% 1/4W
R525 1-249-417-11 CARBON 1K 5% 1/4W F
R527 1-249-429-11 CARBON 10K 5% 1/4W
R528 1-216-081-00 RES, CHIP 22K 5% 1/10W
R529 1-249-429-11 CARBON 10K 5% 1/4W F
R530 1-216-474-11 METAL OXIDE 82 5% 3W F
R531 1-216-474-11 METAL OXIDE 82 5% 3W F
R532 1-249-385-11 CARBON 2.2 5% 1/4W F
R533 1-249-417-11 CARBON 1K 5% 1/4W F
R534 1-249-405-11 CARBON 100 5% 1/4W F
R535 1-215-463-00 METAL 56K 1% 1/4W
R536 1-249-417-11 CARBON 1K 5% 1/4W F
R537 1-215-463-00 METAL 56K 1% 1/4W
R538 1-215-905-11 METAL OXIDE 10 5% 3W F
R539 1-215-905-11 METAL OXIDE 10 5% 3W F
R541
!
1-215-421-00 METAL 1K 1% 1/4W
R542
!
1-215-421-00 METAL 1K 1% 1/4W
R543
!
1-249-389-11 CARBON 4.7 5% 1/4W F
R544
!
1-247-903-00 CARBON 1M 5% 1/4W
R545 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R546 1-215-457-00 METAL 33K 1% 1/4W
R547
!
1-215-477-00 METAL 220K 1% 1/4W
R548 1-215-423-00 METAL 1.2K 1% 1/4W
R549
!
1-215-464-00 METAL 62K 1% 1/4W
R550 1-215-423-00 METAL 1.2K 1% 1/4W
R551 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R552
!
1-215-463-00 METAL 56K 1% 1/4W
R553 1-216-698-11 METAL CHIP 91K 0.50% 1/10W
R554 1-218-756-11 METAL CHIP 150K 0.50% 1/10W
R556 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R557 1-216-079-00 RES, CHIP 18K 5% 1/10W
R558 1-216-671-11 METAL CHIP 6.8K 0.50% 1/10W
R559 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R560 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R561 1-216-474-11 METAL OXIDE 82 5% 3W F
R562 1-215-451-00 METAL 18K 1% 1/4W
R563 1-249-383-11 CARBON 1.5 5% 1/4W F
R564
!
1-216-089-91 RES, CHIP 47K 5% 1/10W
R565 1-215-481-00 METAL 330K 1% 1/4W
R566 1-215-859-00 METAL OXIDE 22 5% 1W F
R567
!
1-216-073-00 RES, CHIP 10K 5% 1/10W
R568
!
1-249-437-11 CARBON 47K 5% 1/4W
R569 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R570 1-249-417-11 CARBON 1K 5% 1/4W
R571 1-215-926-00 METAL OXIDE 33K 5% 3W F
R572 1-249-437-11 CARBON 47K 5% 1/4W
R573 1-247-887-00 CARBON 220K 5% 1/4W
R574 1-249-421-11 CARBON 2.2K 5% 1/4W
R575 1-260-314-11 CARBON 68 5% 1/2W
R576 1-249-437-11 CARBON 47K 5% 1/4W
R577 1-216-471-11 METAL OXIDE 27 5% 3W F
R578 1-216-448-11 METAL OXIDE 39 5% 2W F
R579 1-247-883-00 CARBON 150K 5% 1/4W
R580 1-216-077-91 RES, CHIP 15K 5% 1/10W
R581 1-249-429-11 CARBON 10K 5% 1/4W
R582 1-249-402-11 CARBON 56 5% 1/4W F
R583 1-216-073-00 RES, CHIP 10K 5% 1/10W
R584 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R585 1-249-417-11 CARBON 1K 5% 1/4W
R586 1-249-421-11 CARBON 2.2K 5% 1/4W
R587 1-249-417-11 CARBON 1K 5% 1/4W
R589 1-249-425-11 CARBON 4.7K 5% 1/4W
R590 1-215-453-00 METAL 22K 1% 1/4W
R591 1-214-844-81 METAL 150 1% 1/2W
