Sony CPD-E200 - Page 35

— 45 —
REF.NO. PART NO. DESCRIPTION REMARK
REF.NO. PART NO. DESCRIPTION REMARK
CPD-E200
D
R592 1-214-844-81 METAL 150 1% 1/2W
R594 1-216-033-00 RES, CHIP 220 5% 1/10W
R595
!
1-215-477-00 METAL 220K 1% 1/4W
R596 1-215-423-00 METAL 1.2K 1% 1/4W
R597 1-259-880-11 CARBON 2.2M 5% 1/4W
R599 1-249-417-11 CARBON 1K 5% 1/4W
R600 1-205-998-11 CEMENTED 1 5% 10W
R602 1-219-513-11 CARBON 4.7M 5% 1/2W
R603 1-249-403-11 CARBON 68 5% 1/4W
R604
!
1-220-827-91 REGISTER 560K 5% 1/2W
R605 1-220-778-81 FUSIBLE 0.1 10% 1/2W
R606 1-218-768-11 METAL CHIP 470K 0.50% 1/10W
R607 1-216-081-00 RES, CHIP 22K 5% 1/10W
R608 1-215-479-00 METAL 270K 1% 1/4W
R609 1-216-665-11 METAL CHIP 3.9K 0.50% 1/10W
R610 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R611 1-216-009-91 RES, CHIP 22 5% 1/10W
R612 1-247-791-91 CARBON 22 5% 1/4W
R613
!
1-219-513-11 CARBON 4.7M 5% 1/2W
R614 1-216-345-11 METAL OXIDE 0.47 5% 1W F
R615 1-216-117-00 RES, CHIP 680K 5% 1/10W
R616 1-216-121-91 RES, CHIP 1M 5% 1/10W
R617 1-216-025-91 RES, CHIP 100 5% 1/10W
R618 1-216-635-11 METAL CHIP 220 0.50% 1/10W
R619 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R620 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R621 1-216-098-00 RES, CHIP 110K 5% 1/10W
R622 1-247-791-91 CARBON 22 5% 1/4W
R623 1-216-615-91 METAL CHIP 33 0.50% 1/10W
R624 1-216-611-11 METAL CHIP 22 0.50% 1/10W
R625 1-260-332-51 CARBON 2.2K 5% 1/2W
R626 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R627 1-249-377-11 CARBON 0.47 5% 1/4W F
R628 1-216-674-11 METAL CHIP 9.1K 0.50% 1/10W
R629 1-249-441-11 CARBON 100K 5% 1/4W
R630
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R631
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R632
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R635 1-215-925-11 METAL OXIDE 22K 5% 3W F
R636 1-260-119-11 CARBON 47K 5% 1/2W
R637 1-215-902-11 METAL OXIDE 47K 5% 2W F
R638
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R639
!
1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R640 1-249-381-11 CARBON 1 5% 1/4W F
R642 1-216-641-11 METAL CHIP 390 0.50% 1/10W
R643 1-215-467-00 METAL 82K 1% 1/4W
R645 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R646 1-216-689-11 RES, CHIP 39K 5% 1/10W
R647 1-216-073-00 RES, CHIP 10K 5% 1/10W
R648 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R649 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R654 1-216-344-00 METAL OXIDE 0.39 5% 1W F
R655 1-247-807-31 CARBON 100 5% 1/4W
R656 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R660 1-260-119-11 CARBON 47K 5% 1/2W
R661 1-215-902-11 METAL OXIDE 47K 5% 2W F
R663 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R665 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R703 1-249-410-11 CARBON 270 5% 1/4W
R704 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R705 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R706 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R707 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R708 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R709 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R710 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R711 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R712 1-215-860-11 METAL OXIDE 33 5% 1W F
R713 1-216-347-11 METAL OXIDE 0.68 5% 1W F
R716 1-215-860-11 METAL OXIDE 33 5% 1W F
R717 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R718 1-215-863-11 METAL OXIDE 100 5% 1W F
R719 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R724 1-216-422-11 METAL OXIDE 18 5% 1W F
R727 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R728 1-215-863-11 METAL OXIDE 100 5% 1W F
R729 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R730 1-216-421-11 METAL OXIDE 12 5% 1W F
R731 1-216-295-91 SHORT
R733 1-216-295-91 SHORT
R735 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R737 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R739 1-216-073-00 RES, CHIP 10K 5% 1/10W
R741 1-249-377-11 CARBON 0.47 5% 1/4W F
R743 1-249-377-11 CARBON 0.47 5% 1/4W F
R745 1-216-298-00 RES, CHIP 2.2 5% 1/10W
R747 1-216-298-00 RES, CHIP 2.2 5% 1/10W
R753 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R755 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R903 1-216-049-91 RES, CHIP 1K 5% 1/10W
R904 1-216-049-91 RES, CHIP 1K 5% 1/10W
R905 1-216-295-91 SHORT
R906 1-216-073-00 RES, CHIP 10K 5% 1/10W
R907 1-260-087-81 CARBON 100 5% 1/2W
R908 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R909 1-216-057-00 RES, CHIP 2.2K 5% 1/10W
R912 1-216-049-91 RES, CHIP 1K 5% 1/10W
R913 1-216-025-91 RES, CHIP 100 5% 1/10W
Les composants identifies per un trame et une marque
¡¡
¡¡
¡ sont critiques pour la securite. Ne les remplacer
que par une piece portant le numero specifie.
Note:
The components identified by shading
and mark
¡¡
¡¡
¡ are critical for safety.
Replace only with part number specified.
Note:
