— 46 —
REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK
CPD-E200
R914 1-216-025-91 RES, CHIP 100 5% 1/10W
R915 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R916 1-216-077-91 RES, CHIP 15K 5% 1/10W
R917 1-216-077-91 RES, CHIP 15K 5% 1/10W
R918 1-216-049-91 RES, CHIP 1K 5% 1/10W
R919 1-216-025-91 RES, CHIP 100 5% 1/10W
R920 1-216-049-91 RES, CHIP 1K 5% 1/10W
R921 1-216-295-91 SHORT
R922 1-216-073-00 RES, CHIP 10K 5% 1/10W
R923 1-216-295-91 SHORT
R924 1-216-025-91 RES, CHIP 100 5% 1/10W
R925 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R926 1-216-025-91 RES, CHIP 100 5% 1/10W
R927 1-216-295-91 SHORT
R928 1-216-025-91 RES, CHIP 100 5% 1/10W
R929 1-216-065-91 RES, CHIP 4.7K 5% 1/10W
R931 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R932 1-216-077-91 RES, CHIP 15K 5% 1/10W
R933 1-249-417-11 CARBON 1K 5% 1/4W
R934 1-249-429-11 CARBON 10K 5% 1/4W
R935 1-216-025-91 RES, CHIP 100 5% 1/10W
R936 1-216-025-91 RES, CHIP 100 5% 1/10W
R937 1-216-025-91 RES, CHIP 100 5% 1/10W
R938 1-216-025-91 “RES,CHIP 100 5% 1/10W
R940 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R943 1-249-413-11 CARBON 470 5% 1/4W
R951 1-216-025-91 RES, CHIP 100 5% 1/10W
R953 1-216-073-00 RES, CHIP 10K 5% 1/10W
R954 1-216-073-00 RES, CHIP 10K 5% 1/10W
R957 1-216-017-91 RES, CHIP 47 5% 1/10W
R958 1-216-017-91 RES, CHIP 47 5% 1/10W
VARIABLE RESISTOR
RV501
!
1-241-767-21 RES, ADJ, CERMET 100K
RELAY
RY500 1-515-669-21 RELAY
RY601
!
1-755-067-21 RELAY
SWITCH
S602
!
1-771-757-11 SWITCH, PUSH (1 KEY)
S901 1-692-431-21 SWITCH, TACTILE
SPARK GAP
SG501 1-519-422-11 GAP, SPARK
Note:
The components identified by shading
and mark
¡¡
¡¡
¡
are critical for safety.
Replace only with part number specified.
Note:
H
D
TRANSFORMER
T501
!
1-453-311-11 FBT ASSY NX-4404//X4L4
T503 1-433-979-11 TRANSFORMER, FERRITE (DFT)
T504 1-433-978-11 TRANSFORMER, HORIZONTAL DRIVE
T505 1-431-413-11 TRANSFORMER, FERRITE (HST)
T601
!
1-433-847-12 TRANSFORMER, CONVERTER (SRT)
THERMISTOR
TH501 1-807-796-11 THERMISTOR
TH600
!
1-809-827-11 THERMISTOR, NTC
TH601 1-803-540-11 THERMISTOR
VARISTOR
VA601
!
1-801-268-51 VARISTOR ERZV14D471
CRYSTAL
X901 1-767-641-11 VIBRATOR, CRYSTAL
X902 1-767-933-11 OSCILLATOR, CERAMIC
A-1372-633-A H BOARD, COMPLETE
CAPACITOR
C801 1-104-664-11 ELECT 47MF 20% 10V
CONNECTOR
CN801 * 1-564-510-11 PLUG, CONNECTOR 7P
DIODE
D803 8-719-064-11 DIODE SPR-325MVW
TRANSISTOR
Q801 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
RESISTOR
R801 1-215-417-00 METAL 680 1% 1/4W
R802 1-215-421-00 METAL 1K 1% 1/4W
R803 1-215-427-00 METAL 1.8K 1% 1/4W
R804 1-215-433-00 METAL 3.3K 1% 1/4W
[
H
The components identified by
[[
[[
[ in this manual have been
carefully factory-selected for each set in order to satisfy
regulations regarding X-ray radiation. Should replacement
be required, replace only with the value originally used.
