CPD-E250/CPD-E450
4-089-640-11
Appendix
Preset mode timing table
(For CPD-E250)
Preset mode timing table
(For CPD-E450)
If the input signal does not match one of the factory preset modes
above, the Generalized Timing Formula feature of this monitor
will automatically provide an optimal image for the screen as long
as the signal is GTF compliant.
No. Resolution
(dots × lines)
Horizontal
Frequency
Vertical
Frequency
Graphics
Mode
1640 × 480 31.5 kHz 60 Hz VGA-G
2640 × 480 43.3 kHz 85 Hz VESA
3720 × 400 31.5 kHz 70 Hz VGA-Text
4800 × 600 53.7 kHz 85 Hz VESA
5832 × 624 49.7 kHz 75 Hz Macintosh 16"
Color
6 1024 × 768 60.0 kHz 75 Hz VESA
7 1024 × 768 68.7 kHz 85 Hz VESA
8 1280 × 1024 80.0 kHz 75 Hz VESA
9 1280 × 1024 91.1 kHz 85 Hz VESA
10 1600 × 1200 93.8 kHz 75 Hz VESA
No. Resolution
(dots × lines)
Horizontal
Frequency
Vertical
Frequency
Graphics
Mode
1640 × 480 31.5 kHz 60 Hz VGA-G
2640 × 480 43.3 kHz 85 Hz VESA
3720 × 400 31.5 kHz 70 Hz VGA-TEXT
4800 × 600 53.7 kHz 85 Hz VESA
5832 × 624 49.7 kHz 75 Hz Macintosh 16"
Color
6 1024 × 768 68.7 kHz 85 Hz VESA
7 1152 × 870 68.7 kHz 75 Hz Macintosh 21"
Color
8 1280 × 1024 91.1 kHz 85 Hz VESA
9 1600 × 1200 93.8 kHz 75 Hz VESA
