CX-LEM550
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R319 1-216-857-11 METAL CHIP 1M 5% 1/10W
R320 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R321 1-216-845-11 METAL CHIP 100K 5% 1/10W
R322 1-216-816-11 METAL CHIP 390 5% 1/10W
R323 1-216-821-11 METAL CHIP 1K 5% 1/10W
R324 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R325 1-216-845-11 METAL CHIP 100K 5% 1/10W
R326 1-216-845-11 METAL CHIP 100K 5% 1/10W
R327 1-216-833-11 METAL CHIP 10K 5% 1/10W
R328 1-249-409-11 CARBON 220 5% 1/4W
R331 1-249-409-11 CARBON 220 5% 1/4W
R332 1-249-409-11 CARBON 220 5% 1/4W
R336 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R337 1-216-845-11 METAL CHIP 100K 5% 1/10W
R338 1-249-393-11 CARBON 10 5% 1/4W
R339 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R340 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R341 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R342 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R343 1-249-385-11 CARBON 2.2 5% 1/4W
R348 1-216-821-11 METAL CHIP 1K 5% 1/10W
R349 1-216-842-11 METAL CHIP 56K 5% 1/10W
R350 1-216-833-11 METAL CHIP 10K 5% 1/10W
R351 1-216-833-11 METAL CHIP 10K 5% 1/10W
R352 1-249-409-11 CARBON 220 5% 1/4W
0 R353 1-215-857-71 METAL OXIDE 10 5% 1W
R358 1-216-842-11 METAL CHIP 56K 5% 1/10W
R359 1-260-095-11 CARBON 470 5% 1/2W
0 R360 1-219-787-17 FUSIBLE 5.6 5% 1/4W
0 R361 1-219-787-17 FUSIBLE 5.6 5% 1/4W
R362 1-216-836-11 METAL CHIP 18K 5% 1/10W
R363 1-216-836-11 METAL CHIP 18K 5% 1/10W
R364 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R365 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R366 1-216-837-11 METAL CHIP 22K 5% 1/10W
R367 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R368 1-216-833-11 METAL CHIP 10K 5% 1/10W
R370 1-216-841-11 METAL CHIP 47K 5% 1/10W
R371 1-216-841-11 METAL CHIP 47K 5% 1/10W
R372 1-247-807-31 CARBON 100 5% 1/4W
R373 1-216-845-11 METAL CHIP 100K 5% 1/10W
R374 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-216-833-11 METAL CHIP 10K 5% 1/10W
R388 not supplied
R389 1-216-821-11 METAL CHIP 1K 5% 1/10W
R390 1-216-821-11 METAL CHIP 1K 5% 1/10W
R391 1-260-298-51 CARBON 3.3 5% 1/2W
R392 1-216-809-11 METAL CHIP 100 5% 1/10W
R393 1-249-393-11 CARBON 10 5% 1/4W
R394 1-216-833-11 METAL CHIP 10K 5% 1/10W
R395 1-216-845-11 METAL CHIP 100K 5% 1/10W
R396 1-216-837-11 METAL CHIP 22K 5% 1/10W
R397 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
A-1059-097-A POWER BOARD, COMPLETE (KR)
A-4752-018-A POWER BOARD, COMPLETE (SP, E51)
1-861-721-11 POWER BOARD
************
< CAPACITOR >
C904 1-128-553-11 ELECT 220uF 20% 63V
C905 1-161-055-00 CERAMIC 0.022uF 10% 25V
C906 1-161-055-00 CERAMIC 0.022uF 10% 25V
C907 1-161-055-00 CERAMIC 0.022uF 10% 25V
C908 1-161-055-00 CERAMIC 0.022uF 10% 25V
C909 1-161-055-00 CERAMIC 0.022uF 10% 25V
C910 1-161-055-00 CERAMIC 0.022uF 10% 25V
C911 1-161-055-00 CERAMIC 0.022uF 10% 25V
C912 1-161-055-00 CERAMIC 0.022uF 10% 25V
C913 1-126-943-11 ELECT 2200uF 20% 25V
< CONNECTOR >
* CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CN903 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
D905 8-719-200-02 DIODE 10E-2
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-991-33 DIODE 1SS133T-77
D908 8-719-991-33 DIODE 1SS133T-77
D909 8-719-991-33 DIODE 1SS133T-77
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-063-79 DIODE 1N4002B
D912 8-719-063-79 DIODE 1N4002B
D913 8-719-063-79 DIODE 1N4002B
D914 8-719-063-79 DIODE 1N4002B
D916 8-719-046-47 DIODE 1N5401TM
D917 8-719-046-47 DIODE 1N5401TM
D918 8-719-046-47 DIODE 1N5401TM
D919 8-719-046-47 DIODE 1N5401TM
D920 8-719-991-33 DIODE 1SS133T-77
D921 8-719-991-33 DIODE 1SS133T-77
D922 8-719-991-33 DIODE 1SS133T-77
D923 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0 F904 1-245-420-11 IC LINK 3A 60V
< LINE FILTER >
0 LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)(SP, E51)
< RESISTOR >
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-259-882-11 CARBON 3.3M 5% 1/4W
(AEP, UK)
R904 1-249-393-11 CARBON 10 5% 1/4W
R905 1-249-421-11 CARBON 2.2K 5% 1/4W
R906 1-249-421-11 CARBON 2.2K 5% 1/4W
MAIN POWER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
