Ref. No. Part No. Description Remark
46
CX-LEM550
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0 S901 1-571-309-11 SWITCH (VOLTAGE SELECTOR)(SP, E51)
< TRANSFORMER >
0 T901 1-443-410-11 TRANSFORMER, POWER (AEP, UK, KR)
0 T901 1-443-412-11 TRANSFORMER, POWER (SP, E51)
************************************************************
MISCELLANEOUS
***************
0 5 1-769-079-23 CORD, POWER (KR)
0 5 1-769-744-52 CORD, POWER (EXCEPT KR)
6 1-693-626-11 TUNER (FM/AM) (AEP, UK)
6 1-693-628-11 TUNER (FM/AM) (SP, E51)
6 1-693-629-11 TUNER (FM/AM) (KR)
9 1-469-636-11 CORE, FERRITE (ESD-R-25SD) (AEP, UK, KR)
52 1-757-791-11 WIRE (FLAT TYPE) (16 CORE)(SILVER)
52 1-773-019-11 WIRE (FLAT TYPE) (15 CORE)(BLACK)
53 1-828-965-11 WIRE (FLAT TYPE) (11 CORE)(SP, E51, KR)
53 1-828-985-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
55 1-773-220-11 WIRE (FLAT TYPE) (25 CORE)
56 1-790-378-11 WIRE (FLAT TYPE) (8 CORE) (SILVER)
56 1-828-007-11 WIRE (FLAT TYPE) (8 CORE) (BLACK)
110 1-796-351-51 MECHANISM, SIGNAL CASSETTE
(CMAL1Z240A)
163 1-827-992-11 WIRE (FLAT TYPE) (16 CORE)
164 1-824-048-12 WIRE (FLAT TYPE) (27 CORE)
167 8-820-221-01 DEVICE, OPTICAL PICK-UP
(KSM-213EDP/C2NP)
M301 1-787-103-11 FAN, DC
S101 1-771-853-11 SWITCH, DETECTION
0 T902 1-443-274-11 TRANSFORMER, POWER (AEP, UK)
0 T902 1-443-308-11 TRANSFORMER, POWER (E51, SP)
0 T902 1-443-365-11 TRANSFORMER, POWER (KR)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER
