18
D-E350/E351/E351SR/E353/E355/E356CK
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
Les composants identifiés par une
marque 0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• Abbreviation
CND : Canadian AUS : Australian
FR : French HK : Hong Kong
AR : Argentina JE : Tourist
G : German EA : Saudi Arabia
CH : Chinese EE : East European
C&SA : Central and South America
E13 : AC220-230V area model
E33 : AC100-240V area model
MAIN
* A-3021-693-A MAIN PC BOARD ASSY (E355)
* A-3021-694-A MAIN PC BOARD ASSY (E353)
* A-3021-696-A MAIN PC BOARD ASSY (E350:FR/E351:FR)
* A-3021-697-A MAIN PC BOARD ASSY (E350:EXCEPT FR/
E351:EXCEPT FR/E351SR/E356CK)
**********************
3-222-860-01 TERMINAL (+.-), BATTERY
3-231-411-01 TERMINAL (-), BATTERY
3-234-414-01 TERMINAL (LINK), BATTERY (E353/E355)
A-3174-291-A TERMINAL, (LINK) SUB ASSY (E353/E355)
<CAPACITOR>
C102 1-216-833-11 METAL CHIP 10K 5% 1/16W
C103 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-216-833-11 METAL CHIP 10K 5% 1/16W
C203 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-126-369-11 ELECT 220uF 20% 6.3V
C303 1-115-156-11 CERAMIC CHIP 1uF 10V
C304 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C305 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C306 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C401 1-165-456-21 ELECT 100uF 20% 6.3V
C402 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C404 1-165-456-21 ELECT 100uF 20% 6.3V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C407 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-124-584-00 ELECT 100uF 20% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-115-156-11 CERAMIC CHIP 1uF 10V
C412 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C413 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C415 1-126-369-11 ELECT 220uF 20% 6.3V
C422 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C425 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C426 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C427 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C428 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C429 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C431 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C433 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C434 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C502 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C610 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C611 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C612 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C613 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C614 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C616 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C617 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C618 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C619 1-126-369-11 ELECT 220uF 20% 6.3V
C620 1-115-156-11 CERAMIC CHIP 1uF 10V
C621 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C622 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C623 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C624 1-115-156-11 CERAMIC CHIP 1uF 10V
C625 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C626 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C628 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C629 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C634 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C635 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C637 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C638 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C801 1-115-156-11 CERAMIC CHIP 1uF 10V
C802 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(E355/E356CK)
