8
D-E350/E351/E351SR/E353/E355/E356CK
Pin No. Pin name I/O Description
66 XWAKEUP_O O Wale-up signal output.
67 PGM STD0 – Not used (OPEN).
68 PGMSI_I – Not used (OPEN).
69 PGMSCK_O – Not used (OPEN).
70 P13 O Not used (OPEN).
71 GFS_I I Guard Frame Synchronous signal input.
72 ESPLT_O O ESP’s serial interface latch output.
73 PGMSEL_O – Not used (OPEN).
74 AMUTE_O O Mute ON/OFF control output.
75 VCC2ON_O O Not used (OPEN).
76 XRST_O O System reset output.
77 XPOFF_O O DSP’s power off output.
78 OPSTBY_O O Pick-up’s power supply ON/OFF control.
79 OPG4[_O O RF IC’s gain control.
80 C2POEN_O O C2PO enable.
