– 33 –
FB302 1-500-234-22 FERRITE
FB303 1-216-295-00 METAL CHIP 0
FB304 1-500-234-22 FERRITE
FB306 1-500-234-22 FERRITE
FB401 1-419-256-21 INDUCTOR CHIP 2.2uH
FB402 1-419-256-21 INDUCTOR CHIP 2.2uH
FB501 1-500-234-22 FERRITE
FB502 1-500-234-22 FERRITE
FB601 1-500-234-22 FERRITE
FB603 1-216-295-00 METAL CHIP 0
FB801 1-500-234-22 FERRITE
FB802 1-216-864-11 METAL CHIP 0
FB803 1-500-234-22 FERRITE
< IC >
IC301 8-759-483-60 IC TC9438FNEL
IC302 8-759-522-87 IC TA2120FN(EL)
IC401 8-759-483-61 IC MPC18A26VMEL
IC501 8-759-432-83 IC BA6386K
IC502 8-759-563-54 IC BU9326KS
IC503 8-759-528-79 IC NJU7012F-TE2
IC505 8-759-082-60 IC TC7S66FU
IC601 8-759-484-37 IC SM5902AF
IC603 8-759-538-44 IC MSM51V17400D-10TK-FS
IC701 8-759-483-62 IC MPC17A51VMEL
IC801 8-759-639-93 IC MC68HC05L15SC442720CPB
< JACK >
J301 1-778-696-11 JACK (LINE OUT)
J302 1-580-680-11 JACK (2 / REMOTE)
J401 1-778-153-21 JACK,DC(POLARITY UNIFIED TYPE)
(DC IN 4.5V)
< JUMPER RESISTOR >
JW304 1-216-864-11 METAL CHIP 0 5% 1/16W
JW401 1-216-296-00 METAL CHIP 0 5% 1/8W
JW501 1-216-295-00 METAL CHIP 0 5% 1/10W
JW502 1-216-295-00 METAL CHIP 0 5% 1/10W
< COIL >
L301 1-469-034-11 INDUCTOR 4.7uH
L302 1-414-821-11 INDUCTOR 4.7uH
L303 1-414-821-11 INDUCTOR 4.7uH
L304 1-414-821-11 INDUCTOR 4.7uH
L401 1-414-267-11 INDUCTOR 10uH
L402 1-414-404-11 INDUCTOR 100uH
L502 1-414-267-11 INDUCTOR 10uH
L504 1-414-267-11 INDUCTOR 10uH
L506 1-414-267-11 INDUCTOR 10uH
L507 1-414-267-11 INDUCTOR 10uH
L508 1-216-295-00 METAL CHIP 0
L701 1-414-402-11 INDUCTOR 47uH
L702 1-414-402-11 INDUCTOR 47uH
L801 1-414-916-11 FERRITE 0uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-017-11 DISPLAY PANEL, LIQUID CRYSTAL (E451,
E455)
LCD801 1-803-776-11 DISPLAY PANEL, LIQUID CRYSTAL (E456CK,
E459CK)
< TRANSISTOR >
Q101 8-729-209-06 TRANSISTOR 2SC4213-A
Q201 8-729-209-06 TRANSISTOR 2SC4213-A
Q300 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q302 8-729-907-39 TRANSISTOR IMD2
Q311 8-729-422-51 TRANSISTOR UN5110-QRS
Q401 8-729-044-09 TRANSISTOR 2SD2153T100V
Q402 8-729-044-10 TRANSISTOR MMBF0201NLT1
Q404 8-729-921-93 TRANSISTOR 2SB1182F5-QR
Q405 8-729-920-85 TRANSISTOR 2SD1664-QR
Q501 8-729-216-22 TRANSISTOR 2SA1162-G
Q506 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q507 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q508 8-729-028-74 TRANSISTOR DTA114TUA-T106
Q509 8-729-420-29 TRANSISTOR 2SD1819A
Q801 8-729-420-29 TRANSISTOR 2SD1819A
Q802 8-729-420-29 TRANSISTOR 2SD1819A
Q809 8-729-420-29 TRANSISTOR 2SD1819A
< RESISTOR >
R101 1-216-813-11 RES,CHIP 220 5% 1/16W
R102 1-216-845-11 RES,CHIP 100K 5% 1/16W
R103 1-216-841-11 RES,CHIP 47K 5% 1/16W
R105 1-216-821-11 RES,CHIP 1K 5% 1/16W
R107 1-216-793-11 RES,CHIP 4.7 5% 1/16W
R201 1-216-813-11 RES,CHIP 220 5% 1/16W
R202 1-216-845-11 RES,CHIP 100K 5% 1/16W
R203 1-216-841-11 RES,CHIP 47K 5% 1/16W
R205 1-216-821-11 RES,CHIP 1K 5% 1/16W
R207 1-216-793-11 RES,CHIP 4.7 5% 1/16W
R304 1-216-803-11 RES,CHIP 33 5% 1/16W
R306 1-216-864-11 RES,CHIP 0 5% 1/16W
R307 1-216-821-11 RES,CHIP 1K 5% 1/16W
R308 1-216-864-11 RES,CHIP 0 5% 1/16W
R310 1-216-142-00 RES,CHIP 4.7 5% 1/8W
R312 1-216-815-11 RES,CHIP 330 5% 1/16W
R326 1-216-853-11 RES,CHIP 470K 5% 1/16W
R401 1-218-911-11 METAL CHIP 470K 0.50% 1/16W
R402 1-218-899-11 METAL CHIP 150K 0.50% 1/16W
R403 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R404 1-216-799-11 RES,CHIP 15 5% 1/16W
R406 1-216-304-11 RES,CHIP 3.3 5% 1/10W
R408 1-216-809-11 RES,CHIP 100 5% 1/16W
R409 1-216-837-11 RES,CHIP 22K 5% 1/16W
R413 1-216-845-11 RES,CHIP 100K 5% 1/16W
R414 1-216-845-11 RES,CHIP 100K 5% 1/16W
R415 1-216-815-11 RES,CHIP 330 5% 1/16W
R416 1-216-298-00 RES,CHIP 2.2 5% 1/10W
R417 1-216-298-00 RES,CHIP 2.2 5% 1/10W
R418 1-216-864-11 RES,CHIP 0 5% 1/16W
R419 1-216-849-11 RES,CHIP 220K 5% 1/16W
R421 1-216-833-91 RES,CHIP 10K 5% 1/16W
R423 1-216-853-11 RES,CHIP 470K 5% 1/16W
R429 1-218-895-11 METAL CHIP 100K 0.50% 1/16W
R430 1-218-883-11 METAL CHIP 33K 0.50% 1/16W
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
