– 34 –
R431 1-216-864-11 RES,CHIP 0 5% 1/16W
R433 1-216-821-11 RES,CHIP 1K 5% 1/16W
R501 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R502 1-216-827-11 RES,CHIP 3.3K 5% 1/16W
R503 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R504 1-216-839-11 RES,CHIP 33K 5% 1/16W
R505 1-216-142-00 RES,CHIP 4.7 5% 1/8W
R506 1-216-833-91 RES,CHIP 10K 5% 1/16W
R507 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R508 1-216-833-91 RES,CHIP 10K 5% 1/16W
R509 1-216-835-11 RES,CHIP 15K 5% 1/16W
R510 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R511 1-216-833-91 RES,CHIP 10K 5% 1/16W
R512 1-216-833-91 RES,CHIP 10K 5% 1/16W
R513 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R517 1-216-838-11 RES,CHIP 27K 5% 1/16W
R518 1-216-864-11 RES,CHIP 0 5% 1/16W
R519 1-216-831-11 RES,CHIP 6.8K 5% 1/16W
R521 1-216-827-11 RES,CHIP 3.3K 5% 1/16W
R522 1-216-833-91 RES,CHIP 10K 5% 1/16W
R525 1-216-821-11 RES,CHIP 1K 5% 1/16W
R528 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R529 1-216-864-11 RES,CHIP 0 5% 1/16W
R531 1-216-833-91 RES,CHIP 10K 5% 1/16W
R533 1-216-841-11 RES,CHIP 47K 5% 1/16W
R534 1-216-833-91 RES,CHIP 10K 5% 1/16W
R535 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R538 1-216-833-91 RES,CHIP 10K 5% 1/16W
R539 1-216-864-11 RES,CHIP 0 5% 1/16W
R542 1-216-851-11 RES,CHIP 330K 5% 1/16W
R543 1-216-864-11 RES,CHIP 0 5% 1/16W
R544 1-216-849-11 RES,CHIP 220K 5% 1/16W
R545 1-216-849-11 RES,CHIP 220K 5% 1/16W
R546 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R547 1-216-843-11 RES,CHIP 68K 5% 1/16W
R548 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R549 1-216-833-91 RES,CHIP 10K 5% 1/16W
R550 1-216-864-11 RES,CHIP 0 5% 1/16W
R555 1-216-845-11 RES,CHIP 100K 5% 1/16W
R563 1-216-845-11 RES,CHIP 100K 5% 1/16W
R569 1-216-843-11 RES,CHIP 68K 5% 1/16W
R570 1-216-841-11 RES,CHIP 47K 5% 1/16W
R599 1-216-851-11 RES,CHIP 330K 5% 1/16W
R602 1-216-833-91 RES,CHIP 10K 5% 1/16W
R610 1-216-864-11 RES,CHIP 0 5% 1/16W
R611 1-216-821-11 RES,CHIP 1K 5% 1/16W
R612 1-216-821-11 RES,CHIP 1K 5% 1/16W
R613 1-216-821-11 RES,CHIP 1K 5% 1/16W
R614 1-216-821-11 RES,CHIP 1K 5% 1/16W
R630 1-216-864-11 RES,CHIP 0 5% 1/16W
R632 1-216-864-11 RES,CHIP 0 5% 1/16W
R701 1-216-864-11 RES,CHIP 0 5% 1/16W
R702 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R802 1-216-833-91 RES,CHIP 10K 5% 1/16W
R803 1-216-821-11 RES,CHIP 1K 5% 1/16W
R804 1-216-853-11 RES,CHIP 470K 5% 1/16W
R805 1-216-861-11 RES,CHIP 2.2M 5% 1/16W
R806 1-216-821-11 RES,CHIP 1K 5% 1/16W
R807 1-216-821-11 RES,CHIP 1K 5% 1/16W
R808 1-216-851-11 RES,CHIP 330K 5% 1/16W
R810 1-216-857-11 RES,CHIP 1M 5% 1/16W
R811 1-216-857-11 RES,CHIP 1M 5% 1/16W
R813 1-216-833-91 RES,CHIP 10K 5% 1/16W
R817 1-216-821-11 RES,CHIP 1K 5% 1/16W
R818 1-216-857-11 RES,CHIP 1M 5% 1/16W
R819 1-216-821-11 RES,CHIP 1K 5% 1/16W
R820 1-216-831-11 RES,CHIP 6.8K 5% 1/16W
R821 1-216-829-11 RES,CHIP 4.7K 5% 1/16W
R822 1-216-827-11 RES,CHIP 3.3K 5% 1/16W
R823 1-216-825-11 RES,CHIP 2.2K 5% 1/16W
R824 1-216-823-11 RES,CHIP 1.5K 5% 1/16W
R825 1-216-821-11 RES,CHIP 1K 5% 1/16W
R826 1-216-821-11 RES,CHIP 1K 5% 1/16W
R829 1-216-864-11 RES,CHIP 0 5% 1/16W
R830 1-216-864-11 RES,CHIP 0 5% 1/16W
R879 1-216-857-11 RES,CHIP 1M 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-223-609-21 RES, VAR, CARBON 10K/10K (∑ VOLUME)
RV502 1-223-587-11 RES, ADJ, CARBON 22K (TRACKING GAIN)
RV503 1-223-587-11 RES, ADJ, CARBON 22K (FOCUS GAIN)
< SWITCH >
S301 1-762-078-11 SWITCH, SLIDE (AVLS)
S801 1-762-822-11 SWITCH, PUSH (1 KEY) (OPEN SW)
S802 1-571-754-31 SWITCH, PUSH (1 KEY) (RECHG BAT DET)
S803 1-762-078-11 SWITCH, SLIDE (RESUME)
S804 1-762-078-11 SWITCH, SLIDE (HOLD c)
S805 1-571-760-11 SWITCH, KEYBOARD (PLAY MODE)
S806 1-571-760-11 SWITCH, KEYBOARD (ESP)
S808 1-571-760-11 SWITCH, KEYBOARD (p)
S809 1-571-760-11 SWITCH, KEYBOARD (REPEAT/ENTER)
S810 1-571-760-11 SWITCH, KEYBOARD (=)
S811 1-571-760-11 SWITCH, KEYBOARD (+)
S812 1-571-760-11 SWITCH, KEYBOARD (^)
S813 1-554-088-00 SWITCH, KEY BOARD (SOUND)
< TRANSFORMER >
T401 1-475-573-11 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X301 1-760-307-11 VIBRATOR, CERAMIC (16.9MHz)
X801 1-577-101-11 VIBRATOR, CERAMIC (4.1943MHz)
**************************************************************
MISCELLANEOUS
*************
53 1-690-530-81 LEAD (WITH CONNECTOR)
58 1-660-965-11 PC BOARD, SLIDE FLEXIBLE
! 59 X-4950-476-1 OPTICAL PICK-UP (DAX-11E)
LCD801 1-803-017-11 DISPLAY PANEL, LIQUID CRYSTAL (E451,
E455)
MAIN
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
