D-EJ750/EJ751/EJ753/EJ755/EJ756CK/EJ758CK
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
* A-3021-688-A MAIN BOARD, COMPLETE
(EJ756CK,EJ758CK:US)
* A-3021-689-A MAIN BOARD, COMPLETE
(EJ750:FR,EJ751:FR,EJ755:FR)
* A-3021-690-A MAIN BOARD, COMPLETE (EXCEPT US,FR)
***********************
3-235-312-01 TERMINAL BOARD (RELAY),BATTERY
3-235-313-01 TERMINAL (-), BATTERY
3-235-314-01 TERMINAL (+), BATTERY
<CAPACITOR>
C101 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C110 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C111 1-113-690-11 ELECT CHIP 220uF 20% 4V
C123 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C124 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C201 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C210 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C211 1-113-690-11 ELECT CHIP 220uF 20% 4V
C223 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C224 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C351 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C352 1-126-153-11 ELECT 22uF 20% 6.3V
C353 1-126-153-11 ELECT 22uF 20% 6.3V
C354 1-124-635-00 ELECT 220uF 20% 6.3V
C355 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C357 1-104-849-11 ELECT 22uF 20% 6.3V
C358 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C360 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C361 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C406 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C407 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C409 1-124-584-00 ELECT 100uF 20% 10V
C410 1-124-635-00 ELECT 220uF 20% 6.3V
C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C412 1-124-635-00 ELECT 220uF 20% 6.3V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C415 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C416 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C417 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C418 1-126-369-11 ELECT 220uF 20% 6.3V
C419 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C420 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C421 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C422 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C425 1-115-156-11 CERAMIC CHIP 1uF 10V
C426 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C427 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C428 1-115-156-11 CERAMIC CHIP 1uF 10V
C429 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C430 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C431 1-126-369-11 ELECT 220uF 20% 6.3V
C433 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C435 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C438 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C440 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C441 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C444 1-115-156-11 CERAMIC CHIP 1uF 10V
C446 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C447 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C448 1-124-635-00 ELECT 220uF 20% 6.3V
C450 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C451 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C453 1-115-156-11 CERAMIC CHIP 1uF 10V
C454 1-107-826-11 CERAMIC CHIP 0.1uF 10% 10V
C457 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C461 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C462 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C502 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C601 1-110-569-21 TANTAL. CHIP 47uF 20% 4V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C605 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
