8
D-EJ750/EJ751/EJ753/EJ755/EJ756CK/EJ758CK
Pin No. Pin name I/O Description
SECTION 5
DIAGRAMS
5-1. EXPLANATION OF IC TERMINALS
IC601 (SYSTEM CONTROL) CXD3029R (DSP IC)
1 XRAM O DRAM low address strobe signal outut.
2 XWE O DRAM data input enable signal output.
3 to 6 D0 to 3 I/O DRAM data bus 0 to 3.
7 DCLK O Not used (OPEN).
8 DCKE O Not used (OPEN).
9 XCAS O DRAM column address storobe signal output.
10 WFCK O Not used (OPEN).
11 to 13 A7 to 9 O DRAM address 7 to 9.
14 DVss – Ground terminal for DRAM interface.
15 to 17 A4 to 6 O DRAM addres 4 to 6.
18 XRDE I/O Not used (OPEN).
19 VDD0 – Power supply for digital.
20 CLOCK I Serial data transfer clock input.
21 SDTO I Serial data input.
22 SENS O SENS output.
23 XLAT I Latch input.
24 XSOE I CPU serial data output enable signal input.
25 SYSM I Mute input. “H” : MUTE
26 WDCK O Word clock output.
27 SCOR O SCOR output.
28 XRST I Reset terminal.
29 PWMI I Spindle moter external contorol input.
30 XQOK I/O Not used (OPEN).
31 XWER I/O DRAM write enable signal input.
32 R4M O System clock output.
33 Vss0 – Digital ground terminal.
34 SQCK I Clock input for SQSO read out.
35 SCLK I Clock input for SENS serial date read out.
36 SQSO O Not used (OPEN).
37 XEMP O Not used (OPEN).
38 XWIH O Not used (OPEN).
39 SBSO O Not used (OPEN).
40 EXCK I Not used (Fixed at “L”).
41 XTSL I Not used (Fixed at “L”).
42 HVss – Ground terminal for headphones.
43 HPL O Headphone output (L-CH).
44 HPR O Headphone output (R-CH)..
45 HVDD – Power supply terminal for headphones.
46 XVDD – Power supply terminal for master clock.
47 XTAI I Master clock input.
48 XTAO O Master clock output.
49 XVss – Ground terminal for master clock.
50 AVDD1 – Power supply terminal for analog.
51 AOUT1 O Line out (L-CH).
52 VREFL O VREF terminal (L-CH).
53 AVss1 – Ground terminal for analog.
54 AVss2 – Ground terminal for analog.
