Sony D-EJ750 - MD Assembly and Main Board Removal

5
D-EJ750/EJ751/EJ753/EJ755/EJ756CK/EJ758CK
3-3. “MOTOR ASSY, TURN TABLE
(SPINDLE) (M901)”
1 CN501
MD ASSY
Main board
Cabinet (rear) sub ASS
Y
2 CN502 (black)
3 CN503 (white)
3-2. MD ASSY, MAIN BOARD
2
Motor ASSY, Turn tabl
e
(Spindle) (M901)
1 Screws
(B1.7x5)
Chassis
