4
D-EJ750/EJ751/EJ753/EJ755/EJ756CK/EJ758CK
SECTION 3
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
3-1. UPPER LID SUB ASSY, CABINET (FRONT) SUB ASSY
z
The equipment can be removed using the following procedure.
Upper lid sub ASSY,
Cabinet (front) sub ASSY
MD ASSY “Motor ASSY, turn table (spindle) (M901)”, Optical pick-up (DAX-25E),
“Motor ASSY (Sled) (M902)”
Main board
Set
1
2
1
2Push in
Insert the point
• "SPRING FULL OPEN" REMOVAL
• "SPRING FULL OPEN" INSTALL
6 Switch unit
flexible board
5 Connector cover
3 Spring (full open), right
2 Spring (full
open), right
3 Spring (full
open), left
6 Spring
(full open),
left
5
2
1
4
1 Switch unit
flexible board
CN801
2
3
8 Claw
7 Six screws (B2)
8 Claw
8 Claw
1 Open
Cabinet (rear) sub ASSY
Cabinet (front)
sub ASSY
Upper lid sub ASSY
4
9
• CAUTION DURING ASSSEMBLY
