D-EJ775
7
knob (GPRO)
2 eight screws (B2)
1 Open battery case lid.
4 cabinet (upper) sub assy
Note : On installation of cabinet (upper) sub assy,
adjust the position of two switch (S803)
and knobs (GPRO).
3 claw
S803
3 claw
3 claw
3-3. PLATE (SPRING)
3-4. CABINET (UPPER) SUB ASSY
4 plate (spring)
3 spring (full open. A)
2
1
two screws
3 spring (full open. B)
