35
D-EJ775
MAIN (SUFFIX-11)
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3021-759-A MAIN BOARD, COMPLETE (SUFFIX-11) (JE)
* A-3021-760-A MAIN BOARD, COMPLETE (SUFFIX-11) (FR)
* A-3021-812-A MAIN BOARD, COMPLETE (SUFFIX-11)
(EXCEPT FR, JE)
**********************
< BATTERY TERMINAL >
BT400 3-239-264-01 TERMINAL (+), BATTERY
BT401 3-239-263-01 TERMINAL BOARD (RELAY), BATTERY
BT402 3-239-265-01 TERMINAL (-), BATTERY
< CAPACITOR >
C102 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C106 1-125-899-11 TANTALUM CHIP 220uF 20% 4V
C107 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-125-899-11 TANTALUM CHIP 220uF 20% 4V
C207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-110-569-11 TANTALUM CHIP 47uF 20% 6.3V
C303 1-115-156-11 CERAMIC CHIP 1uF 10V
C304 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C305 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C307 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C401 1-117-887-11 TANTALUM CHIP 220uF 20% 6.3V
C402 1-107-686-11 TANTALUM CHIP 4.7uF 20% 16V
C404 1-111-253-11 TANTALUM CHIP 100uF 20% 6.3V
C405 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C406 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C407 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C408 1-128-964-11 TANTALUM CHIP 100uF 20% 6.3V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-115-156-11 CERAMIC CHIP 1uF 10V
C412 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C413 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C415 1-117-887-11 TANTALUM CHIP 220uF 20% 6.3V
C416 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C417 1-115-156-11 CERAMIC CHIP 1uF 10V
C418 1-115-156-11 CERAMIC CHIP 1uF 10V
C422 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C425 1-104-908-11 TANTALUM CHIP 47uF 20% 4V
C426 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C427 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Refer to “SERVICING NOTES” (page 3) for
identification of MAIN board.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µ PB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
C429 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C431 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C432 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C434 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C435 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C436 1-115-156-11 CERAMIC CHIP 1uF 10V
C437 1-104-852-11 TANTALUM CHIP 22uF 20% 6.3V
C438 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C439 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C440 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C441 1-115-156-11 CERAMIC CHIP 1uF 10V
C442 1-111-253-11 TANTALUM CHIP 100uF 20% 6.3V
C443 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C444 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C502 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C503 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C602 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C605 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C606 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C607 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C608 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C609 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C610 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C611 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C612 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C613 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C614 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C616 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C617 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C618 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C619 1-111-253-11 TANTALUM CHIP 100uF 20% 6.3V
C620 1-115-156-11 CERAMIC CHIP 1uF 10V
C621 1-115-156-11 CERAMIC CHIP 1uF 10V
C622 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C623 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C624 1-115-156-11 CERAMIC CHIP 1uF 10V
C625 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C626 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C627 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C628 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C629 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
•Abbreviation
AUS: Australian model
CH : Chinese model
CND : Canadian model
E13 : 220 – 230 V AC area in E model
E33 : 100 – 240 V AC area in E model
EE : East European model
FR : French model
HK : Hong Kong model
JE : Tourist model
KR : Korean model
TW : Taiwan model
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
