Sony D-EJ775 - Page 36

Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
36
D-EJ775
MAIN (SUFFIX-11)
C630 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C634 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C635 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C801 1-115-156-11 CERAMIC CHIP 1uF 10V
C802 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C804 1-127-576-21 CAP, CHIP CERAMIC 22000PF B
C806 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C813 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C814 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C818 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C819 1-104-847-11 TANTALUM CHIP 22uF 20% 4V
< CONNECTOR >
* CN501 1-815-832-21 CONNECTOR, FFC/FPC (ZIF) 15P
* CN502 1-785-877-21 HOUSING, CONNECTOR 4P
CN503 1-784-342-21 HOUSING, CONNECTOR 2P
< DIODE >
D301 8-719-069-54 DIODE UDZSTE-175.1B
D302 8-719-069-54 DIODE UDZSTE-175.1B
D303 8-719-069-54 DIODE UDZSTE-175.1B
D304 8-719-069-54 DIODE UDZSTE-175.1B
D403 8-719-404-50 DIODE MA111-TX
D404 8-719-085-43 DIODE MA2YD2300LS0
D405 8-719-085-43 DIODE MA2YD2300LS0
D406 8-719-072-70 DIODE MA2ZD14001S0
D408 8-719-404-50 DIODE MA111-TX
D409 8-719-069-54 DIODE UDZSTE-175.1B
D410 8-719-069-54 DIODE UDZSTE-175.1B
D411 8-719-069-54 DIODE UDZSTE-175.1B
D412 8-719-069-54 DIODE UDZSTE-175.1B
D413 8-719-069-54 DIODE UDZSTE-175.1B
D801 8-719-072-70 DIODE MA2ZD14001S0
D803 8-719-064-07 LED SML-310LTT (CHARGE)
< IC >
IC302 8-759-522-87 IC TA2120FN (EL)
IC401 6-701-638-01 IC BH6571KVT
IC402 6-701-639-01 IC XC6201P212MR
IC404 6-701-882-01 IC MM1385ANLE
IC405 8-759-827-34 IC XC61CN1402MR
IC406 6-701-860-01 IC TB2127AFN (EL)
IC601 6-701-637-01 IC BU9355KV
IC603 8-759-679-04 IC MSM51W4400E
IC801 6-801-347-01 IC T5AJ4-3N53
< JACK >
J301 1-815-088-61 JACK, HEADPHONE (2)
J401 1-793-156-31 JACK, DC (DC IN 4.5V)
< COIL >
L101 1-412-987-41 INDUCTOR 4.7uH
L201 1-412-987-41 INDUCTOR 4.7uH
L401 1-414-406-41 INDUCTOR 220uH
L402 1-419-403-41 CHOKE COIL 47uH
L404 1-414-398-11 INDUCTOR 10uH
L405 1-414-398-11 INDUCTOR 10uH
L406 1-414-392-41 INDUCTOR 1uH
L407 1-414-392-41 INDUCTOR 1uH
L415 1-414-398-11 INDUCTOR 10uH
L501 1-469-527-11 INDUCTOR 47uH
L502 1-469-527-11 INDUCTOR 47uH
L503 1-469-527-11 INDUCTOR 47uH
L601 1-414-398-11 INDUCTOR 10uH
L602 1-469-570-21 INDUCTOR 10uH
L603 1-469-570-21 INDUCTOR 10uH
L604 1-469-525-11 INDUCTOR 10uH
L802 1-469-527-11 INDUCTOR 47uH
< TRANSISTOR >
Q401 8-729-054-79 TRANSISTOR 2SB167900LSO
Q402 8-729-029-10 TRANSISTOR DTC143TUA-T106
Q403 8-729-921-95 TRANSISTOR 2SB1182F5-QR-TLQR
Q404 8-729-921-80 TRANSISTOR 2SD1781K-T146-QR
Q405 8-729-231-75 TRANSISTOR 2SC4116GL-TE85L
Q407 6-550-071-01 TRANSISTOR 2SB169300LSO
Q601 8-729-054-79 TRANSISTOR 2SB167900LSO
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT FR)
R103 1-216-837-11 METAL CHIP 22K 5% 1/10W
(FR)
R105 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT FR)
R105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(FR)
R108 1-216-817-11 METAL CHIP 470 5% 1/10W
R109 1-216-793-11 RES-CHIP 4.7 5% 1/10W
R201 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-833-11 METAL CHIP 10K 5% 1/10W
(EXCEPT FR)
R203 1-216-837-11 METAL CHIP 22K 5% 1/10W
(FR)
R205 1-216-837-11 METAL CHIP 22K 5% 1/10W
(EXCEPT FR)
R205 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(FR)
R208 1-216-817-11 METAL CHIP 470 5% 1/10W
R209 1-216-793-11 RES-CHIP 4.7 5% 1/10W
R301 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R401 1-216-845-11 METAL CHIP 100K 5% 1/10W
R403 1-216-833-11 METAL CHIP 10K 5% 1/10W
R405 1-216-857-11 METAL CHIP 1M 5% 1/10W
R406 1-216-845-11 METAL CHIP 100K 5% 1/10W
R407 1-216-853-11 METAL CHIP 470K 5% 1/10W
R408 1-216-817-11 METAL CHIP 470 5% 1/10W
R410 1-216-821-11 METAL CHIP 1K 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R412 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R413 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R414 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R415 1-218-903-11 METAL CHIP 220K 0.5% 1/16W
R416 1-218-887-11 METAL CHIP 47K 0.5% 1/16W
R417 1-216-841-11 METAL CHIP 47K 5% 1/10W
